AC/DC Current Clamp Meter 200A With NCV/Analog Display Function

0 reviews • Write a review

from

$253.39

Ex Tax: $253.39

Stock: In Stock
Model: RDDLZ-CLAM-FC-36
Weight: 1.00
SKU: RDDLZ-CLAM-FC-36

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Tips: What's the analog bar chart display function of current clamp meter?
Nowadays, there are two types of meter, one is the digital meter and the other is the analog meter. The digital meter has a LCD display and the operators can read value very intuitively and easy. In this respect, analog meters are incomparable, but analog meters also have their own unique advantages, that is, the instantaneous deflection of the pointer can be used to reflect the changes in the properties of the measured object. In order to retain this feature of the analog meter, the digital meter uses an analog bar chart on LCD display to simulate the pointer function of the analog meter.
If both DC and AC signals are present in the signal under test, the practical value of analog bar chart is immediately obvious. For example, when using DC function of AC/DC current clamp meter to measure the stabilized voltage supply during maintenance, take a look at the analog bar chart. If the analog bar has dithered, it means that the DC voltage contains AC voltage. The stabilized voltage supply is not stable.

Builder in Product TAB

NEW! Since Journal 3.2, the much improved T.A.B (Tabs Accordion Blocks) system supports the page builder inside the tab content. Unlimited Blocks, Tabs or Accordions with any HTML content or the builder interface (supporting custom rows/columns/modules) can be assigned to any individual product or to certain groups of products, like entire categories, brands, products with specific options, attributes, price range, etc. You can indicate any criteria via the advanced product assignment mechanism and only those products matching your criteria will display the modules. Also, any module can be selectively activated per device (desktop/tablet/phone), customer login status and other criteria. Imagine the possibilities.

Basics	Model	RDDLZ-FC-36
	Weight	175g
	Size (LWH)	1646532mm
	Display	4 digit LCD display
	Maximum display value	2000~9999
	Power supply	DC 3V, 2 AAA batteries
	Maximum jaw opening size	18mm
	Woring environment	Temperature: 0℃~30℃ (32℉~86℉), relative humidity:＜90%, altitude: ＜3000m
	Storage environment	Temperature: -25℃~60℃ (-14℉~140℉), relative humidity:＜90%
	Accessories	A pair of test probes, a user manual, 2 AAA batteries
Functions	Item	Range	Accuracy
	DC current	200A	±(2.5%+5 digits)
	AC current	200A	±(2.5%+8 digits)
	DC voltage	600V	±(0.5%+1 digits)
	AC voltage	600V	±(1.5%+2 digits)
	NCV AC voltage	100V~600V
	Resistance	999.9Ω
Special functions	NCV	Non-contact voltage test
	NCV indicating light	Inspection light for NCV
	Analog display	Analog bar chart on LCD display
	Diode test	Display forward voltage value of diode
	On-off buzzer	Continuity test buzzer
	Data hold	Hold the reading and peak value when taking a measurement
	Automatic power off	Automatic power off when 15 minutes no operation
	Overload protection	Overload protection for 100% range
	Range selection	Automatic range selection and manual range selection
	Backlight	Backlight for LCD display
	LED torch	A LED torch for night lighting
	ZERO	Zero resetting for relative value
