10 KVA Single Phase Automatic Voltage Stabilizer For Home

0 reviews • Write a review

from

$1,082.36

Ex Tax: $1,082.36

Stock: In Stock
Model: RDDLZ-AVS-1P10K
Weight: 1.00
SKU: RDDLZ-AVS-1P10K

Available Options

Phase

Output Voltage

Output Voltage (AC)

Extended Warranty

Textarea

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Cheap and high quality 10 kVA Single Phase AC Automatic Voltage Stabilizer for Home used with input voltage range 95-125V/ 190-250V, 110V±3%/ 220V±3% output voltage, easy to install and operate, protects the equipment or electronic appliances against voltage fluctuation.

Specifications

Product Name	Automatic Voltage Stabilizer
Model Number	RDDLZSVC-10000VA
Technology	Relay Control System+Programmed control computerized+control algorithm relay"Cross zero"
Capacity	10 kVA (The power capacity of the voltage stabilizer needs to be 1.5~2 times greater than the load power)
Phase	Single Phase
Input Voltage Range	±15% tolerance of output voltage
Output Voltage*	220V±3%/ 230V±3%/ 240V±3%/ 110V±3% (Optional)
Adjust Time	<1sec. (Against 10% input voltage deviation)
Frequency	50Hz/60Hz
Current Type	AC
Protection Over Voltage	<250±2V
Protection Lack Voltage	<185±2V
Ambient Temperature	-10°C~+40°C
Insulation Resistance	≥5MΩ
Temperature Protection	110℃±10℃
Relative Humidity	<90%
Wave Form Distortion	No additional waveform distortion
Efficiency	>95%
Display	LED
Protection Grade	IP20
Dielectric Strength	1500V/min
Certification	CE, RoHS
Warranty Period	12 months
Weight	28 Kg/ 70 Kg
Size	LxWxH=580x300x270mm
Note: The provided 10 kVA voltage stabilizer is 1-phase (L, N, G) by Europe standard. And we can customize the split phase (L1, L2 + G) like USA standard ("G" can only be grounded), just confirm with us by email after ordering.

Details

Tips: Safety device of the voltage stabilizer

The voltage stabilizer below 3 kVA uses a fuse for overload or short circuit protection, and the AC voltage stabilizer above 5 kVA uses a small circuit breaker or small air switch for overload or short circuit protection. When the voltage stabilizer is working, if fuse is blown or the automatic air circuit breaker trips, it should be shut down to check the load and the voltage stabilizer.
Visit blog post Safety Tips for Using Voltage Stabilizer.
