2 KVA Single Phase Automatic Voltage Stabilizer For Home

0 reviews • Write a review

from

$360.38

Ex Tax: $360.38

Stock: In Stock
Model: RDDLZ-AVS-1P2K
Weight: 1.00
SKU: RDDLZ-AVS-1P2K

Available Options

Display

Output Voltage (AC)

Extended Warranty

Textarea

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Protection Functions

Temperature Protection: Mounted on the coil temperature sensor, when the temperature reaches 110, the voltage regulator automatic protection to cuts off the output.
Overload Protection: When the load power reaches 120%, the stabilizer automatically protects and cuts off the output.
Under Voltage Protection: When the output voltage is lower than 140V, the underpressure indicator light rises and the output is cut off.
Over Voltage Protection: When the output voltage is higher than 260V, the overpressure indicator light rises and the output is cut off.
Lightning Protection: Integrated protection system to prevent direct lightning or lightning electromagnetic pulse damage to the building itself or internal equipment.

Specifications

Product Name	Automatic Voltage Stabilizer
Model Number	RDDLZTND-2000
Technology	Relay Control System+Programmed control computerized+control algorithm relay "Cross zero"
Capacity	2 kVA (The power capacity of the voltage stabilizer needs to be 1.5~2 times greater than the load power)
Phase	Single Phase
Input Voltage Range	±15% tolerance of output voltage
Output Voltage*	220V±3%/ 230V±3%/ 240V±3%/ 110V±3% (Optional)
Adjust Time	<1sec. (Against 10% input voltage deviation)
Frequency	50Hz/60Hz
Current Type	AC
Protection Over Voltage	<250±2V
Protection Lack Voltage	<185±2V
Ambient Temperature	-10°C~+40°C
Insulation Resistance	≥5MΩ
Temperature Protection	110℃±10℃
Relative Humidity	<90%
Wave Form Distortion	No additional waveform distortion
Efficiency	>95%
Display	Mechanical or LCD (Optional)
Protection Grade	IP20
Dielectric Strength	1500V/min
Certification	CE, RoHS
Warranty Period	12 months
Weight	5.25 Kg (Mechanical display type), 15 Kg (LCD type)
Size (LWH)	270240x200mm (Mechanical display type), 250250*300 (LCD type)
Note: The provided 2 kVA voltage stabilizer is 1-phase (L, N, G) by European standards. Split phase (L1, L2 + G) like USA standard can't be customized.

Details

Tips: How does a voltage stabilizer work?

A voltage stabilizer is a device that stabilizes the output voltage, it consists of a voltage regulation circuit, control circuit and servo motor. When the input voltage or load changes, the control circuit samples, compares, and amplifies the variation, then it drives the servo motor to rotate to change the position of the voltage regulator's carbon brush. By automatically controlling the coil's turns ratio, it ensures a stable output voltage.
As some electrical appliances contain coil packs, eddy current blocking the current would generate at the initial stage of power supply, the eddy current will weaken the instantaneous voltage when electrical appliances start, and thereof lead to a slow start-up, as well as strengthening the transient voltage generated after open circuit, which may cause sparks to damage circuits. So a voltage stabilizer is needed to protect the normal operation of the circuit.
