Nema 23 Stepper Motor, 3 Phase, 5.8A, 1.5N·m

0 reviews • Write a review

from

$94.69

Ex Tax: $94.69

Stock: In Stock
Model: RDDLZ-STEP-23L580
Weight: 1.00
SKU: RDDLZ-STEP-23L580

Available Options

Textarea

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

3 phase bipolar stepper motor with 3 lead wires is convenient to adjust the speed, long service life and low maintenance cost. This hybrid stepper motor with 8mm shaft, is used in CNC machine, drawing equipment and sewing machine, robot arm and 3D printer.

Physical Specification

Model Number: RDDLZ-FY56TL580A
Flanged Size: 57 x 57mm (Nema 23)
Motor Length: 76mm
Shaft Diameter: 8mm
Number of Leads: 3 wire
Weight: 1.0kg

Electrical Specification

Motor Type: Bipolar Stepper
Step Angle: 1.8°
Rated Current: 5.8A
Holding Torque: 1.5 N·m (150 N·cm, 212.5 Oz.in)
Phase Resistance: 0.55Ω
Phase Inductance: 1.7mH
Rotor Inertia: 480g·cm²

Dimensions (Unit: mm)

L=76mm

Wiring Diagram

Speed-Torque Curve Diagram

Details

Tips: The reason why stepper motor does not run after power on

Stepper motor is a kind of induction motor. Its working principle is to use electronic circuit to change direct current into time-sharing power supply. And multi-phase sequential control current. Use this kind of current to supply power to the motor to work normally. A stepper motor driver is required for power supply and multi-phase. There may be three reasons why the motor does not run after power on:

Overload and stall.
The motor is offline.
The control system has a pulse signal to the stepper motor driver or there is a problem with the wiring.
