Laser Belt Tension Meter

0 reviews • Write a review

from

$832.54

Ex Tax: $832.54

Stock: In Stock
Model: RDDLZ-TM500
Weight: 1.00
SKU: RDDLZ-TM500

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Reliable laser belt tension meter with ±5% accuracy, max frequency 500Hz. The belt tension meter can measure the natural vibration frequency of the belt through the emission and reception of the laser, and then calculate the tension value of the belt by combining the input belt mass and the free belt length.

Specification

Model	RDDLZ-BTT2880R5
Measuring Range	10-500 Hz
Input Range	Max. 99.9 m
Belt Quality	Max. 999.9 g/m
Digital Sampling Error	＜1%
Display Error	±1 Hz
Total Error	＜5%
Operating Temperature	10℃~50℃
Transport Temperature	-5℃~70℃
Display	LCD
Units of Measurement	m, kg/m, N
Power Supply	4*1.5V AAA
Optical Path Measurement Distance	3-20mm
Sensor Depth	about 66mm
Meter Size	Host: 1787234mm Sensor: 1242112mm

Details

Applications

Tension meters are instruments that measure tension in cable, fiber, belts and webs, or sheets. RDDLZ tension meter mainly used in belt tension measurement can also be applied to measure the tension of objects such as tapes, and wires. Widely applied in industries of automobile, textile, cables, wires, plastic films, paper, and printing.

Tips: Precautions when using the belt tension meter

The calibration of belt tension meter must be calibrated according to the standard method, otherwise, it will cause the measurement error in the instrument. Keep in mind that the measuring head must be removed from the belt when zeroing, and the jaw knob must be completely loosened. Moreover, the belt tension meter should be calibrated regularly.
If the belt tension meter will not be used for a long time, it is best to take out the battery to prevent the battery from rotting or leaking and causing damage to the instrument.
The belt tension gauges of different measuring heads will be different with the rotation of the engine, which is caused by different internal loads on the crankshaft during rotation.
Keep in mind that the measuring head must be removed before rotating the machine shaft. If a long-term measurement is performed, it is best to calibrate a zero every 10 minutes.
