1 KVA Single Phase Variac Voltage Regulator

0 reviews • Write a review

from

$256.32

Ex Tax: $256.32

Stock: In Stock
Model: RDDLZ-VVR-1K
Weight: 1.00
SKU: RDDLZ-VVR-1K

Available Options

Input Voltage X Frequency

Textarea

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

1 kVA variac transformer single phase, frequency 50Hz or 60Hz, 110V/220V input voltage is optional.

Note: Support the split phase (L1,L2+N,G), Please contact us.

1 kVA Single Phase Variac Voltage Regulator Features

1 kVA variac variable transformer, single phase, working frequency is 50Hz, rated input voltage is 220V. It is a light weight, low cost and long life line reactor for generator.

1 kVA Single Phase Variac Voltage Regulator Specifications

Model	RDDLZ-TDGC2-1K
Phase No	1
Frequency	50/60Hz	60Hz
Rated Input Voltage	220V	110V
Rated Output Voltage	0~250V	0~130V
Rated Capacity	1 kVA	1 kVA
Max Output Current	3.2AA	6.1A
Usage	SVC
Current Type	AC
Actual Output Current	(actual output voltage * rated current) / maximum output voltage
Type	Contact Type Regulators
Weight	6kg
Dimension	440245450mm

1 kVA Sing Phase Variac Voltage Regulator Detail

Tips: Characteristics of Variac Voltage Regulator

Adopt vacuum adjustment switch, voltage adjustment sensitivity and output stability.
When the grid voltage fluctuates, in order to provide a high-quality stable voltage, the voltage of the transformer must be adjusted.
The integrated voltage regulator transformer has compact structure, small footprint and convenient installation.
Tap-changer power distribution automatic controller, convenient for on-site remote control, can be provided for computer interface.
