10 KVA Single Phase Variac Voltage Regulator

0 reviews • Write a review

from

$1,485.36

Ex Tax: $1,485.36

Stock: In Stock
Model: RDDLZ-VVR-10K
Weight: 1.00
SKU: RDDLZ-VVR-10K

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Cheap price single phase variac voltage regulator, 10 kVA, 50Hz frequency, with long service life time, axle design, porous heat dissipation shell, accurate meter, all copper coil, long service life.

Note: Support the split phase (L1,L2+N,G), Please contact us.

10 kVA Single Phase Variac Voltage Regulator Features

10 kVA and single phase.
High quality and high performance.
32A rated output current and 0-250V rated output voltage, 220V rated input voltage.
Widely used in various power supply places with a frequency of 50 Hz.
Affordable and safety variac voltage regulator.

10 kVA Single Phase Variac Voltage Regulator Specifications

Model		RDDLZ-TDGC2-10K
Phase No		1
Frequency		50/60Hz
Rated Input Voltage		220V
Rated Output Voltage		0-250V
Rated capacity		10 kVA
Max Output Current		32A
Usage		SVC
Current Type		AC
Type		Contact type regulators
Weight		32.5kg
Actual Output Current		(actual output voltage * rated current) / maximum output voltage
Dimension	L	370mm
	W	310mm
	H	500mm

10 kVA Single Phase Variac Voltage Regulator Detail

Tips: Structure of single-phase voltage regulator

Structure: The single-phase large capacity voltage regulator is assembled by several units of the same specification, the brush of each unit contact group is mounted on the same spindle. The coil input end is connected in parallel, and the output end is connected with a balanced reactor to balance the current distribution between the units while simulating the circulating current.
