6 Inch Flanged Y Strainer

0 reviews • Write a review

from

$1,168.46

Ex Tax: $1,168.46

Stock: In Stock
Model: RDDLZ-FYS-150
Weight: 1.00
SKU: RDDLZ-FYS-150

Available Options

Short Description

Material

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Note: This Y type strainer cannot be used for drinking water.

6 inch (DN150) stainless steel flanged strainer, Y type, is available with PN16 working pressure, SS 304/316 material, which is the perfect solution for effective and reliable protection of pumps, valves and instruments.

Specifications

Model: RDDLZ-GL41H
Type: Y Type Strainer
Nominal Diameter: 6 inch (DN150)
Working Pressure: PN16
Product Material: 304/316 Stainless Steel
Connection Form: Flange
Temperature Range: -40°C~180°C
Weight: 30.6kg

Dimensions (Unit: mm)

Main Part Materials
NO.	Part Name	Materials	QTY
1	BODY	CF8/CF8M	1
2	FILTER	S304/S316	1
3	JOINT GASKET	PTRE/RPTFE	1
4	CAP	CF8/CF8M	1
5	BOLT OUTER HEXAGON	S304	4-12

DN	b	L±1.05	D	D1	D2	T	f	z-φd
150	150	405	285	240	211	24	2	8-φ22

Applications

Y-type strainers can remove impurities, debris, and solid particles from fluid or gas pipelines in industrial and commercial applications. They are typically used in applications where a high flow rate is required, and where there is a risk of damage to equipment or processes from the presence of solid particles.

Tips: Flanged Y Strainer vs. Thread Y Strainer

The choice between a flanged Y strainer and a threaded Y strainer depends on specific application requirements and the characteristics of the fluid system.

Flanged Y Strainer
Flanged Y strainers are advantageous in applications where a secure and leak-free connection is crucial. The flanges allow for easy installation and removal from pipelines, making maintenance more convenient. These strainers are often used in industrial settings with higher flow rates, where a robust and reliable connection is necessary. The flanged design is particularly suitable for larger pipe sizes and systems where pressure considerations are significant.

Threaded Y Strainer
Threaded Y strainers are more suitable for smaller pipe sizes and applications where ease of installation and maintenance is a priority. They are commonly used in situations where flanged connections might be impractical or unnecessary. Threaded strainers are simpler to install without the need for welding or complex sealing mechanisms, making them ideal for smaller-scale systems, plumbing, and situations where frequent removal for cleaning is anticipated.

In summary, RDDLZ provides 1/2 inch to 6 inch Y type strainers, the choice between flanged and threaded Y strainers involves considerations of system size, pressure requirements, ease of installation, and the specific demands of the application.
