2" Brass Ball Valve, 2 Piece

0 reviews • Write a review

from

$94.89

Ex Tax: $94.89

Stock: In Stock
Model: RDDLZ-BBV-DN50
Weight: 1.00
SKU: RDDLZ-BBV-DN50

Available Options

Textarea

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Note:

Unsalable status.
This brass ball valve can not be used for drinking water.

The valve body is made from high-quality brass forging to prevent leakage. Brass ball valve is manufactured by a high-precision special machine with low flow resistance. The medium inside the valve body has a straight channel, and the medium flows in a straight line.

Specification

Model: RDDLZ-BBV-DN50
Size: 2 inch (DN50)
Nominal Pressure: 1.6MPa
Body Material: Brass
Connection Type: Thread
Standard: Compliant with ISO 228 Standard
Applicable Temperature: -10℃≤T≤120℃
Working Medium: Water, Oil, Non-Corrosive and Non-Combustible Gas
Weight: 1400g

Dimensions & Details (Unit: mm)

DN	Size	L	B	H	D
50	2	94.5	44	89	140

Number	1	2	3	4	5	6	7	8	9
Component	Valve Body	Valve Cap	Valve Seat	Valve Ball	Valve Stem	Filler	Iron Handle	Pressure Cap	Locknut
Material	Brass	Brass	PTFE	Iron	Brass	PTFE	Iron	Brass	Stainless Steel

Tips: What is a fixed ball valve?

The fixed ball valve has two body structures: two-piece and three-piece. The middle flange is connected by bolts. The seal is made of reinforced PTFE and embedded in the stainless steel ring. The rear of the steel ring is provided with a spring to ensure that the valve seat is close to the ball. Keep sealed. The upper and lower valve stems are equipped with PTFE bearings to reduce friction and save labor. There is an adjustment plate at the bottom of the small shaft to ensure the joint position of the ball and the sealing ring. Full bore: The valve flow aperture is consistent with the inner diameter of the pipeline, so that the pipeline can be cleaned.
