1" Stainless Steel Globe Valve

0 reviews • Write a review

from

$161.86

Ex Tax: $161.86

Stock: In Stock
Model: RDDLZ-GV-1SSGV
Weight: 1.00
SKU: RDDLZ-GV-1SSGV

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Globe stop valve can be used in machinery and petrochemical industry. 1" stainless steel globe valve is suitable for water and oil medium. Working temperature of this type globe valve between -20 ℃ and 260 ℃.

Features:

Simple and compact appearance.
NPT threaded connection for easy installation of pressure gauge and pipe.
304 stainless steel has the characteristics of corrosion resistance and high temperature resistance.

Specification:

Model: RDDLZ-HNV-N16MF
Port Size: 1 inch
Structure: inner and outer thread
Pressure: 0-6000 psi
Temperature: -20 ℃ ~ + 260 ℃
Medium: oil, water, steam

Dimension (Unit: mm)

Model	T	L	S	A	B
HNV-N16MF	NPT 1"	95	45	120	60

Tips: Types of Globe Valve

Oblique globe valve. In the straight flow or Y shape stop valve, the valve body flow channel and the main channel into a diagonal, so that the damage of the flow state is smaller than the conventional stop valve, so the pressure loss through the valve is correspondingly small.
Angle globe valve. The fluid only needs to change direction once so that the pressure drop through the valve is smaller than in conventionally constructed globe valves.
