USB Temperature Data Logger With LCD Display

0 reviews • Write a review

from

$58.69

Ex Tax: $58.69

Stock: In Stock
Model: RDDLZ-TDL-U06
Weight: 1.00
SKU: RDDLZ-TDL-U06

Available Options

Textarea

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Low cost temperature data logger has LCD display which shows you the real time data. The temp date recorder is a simple and reliable focused on temperature recording in pharmaceuticals, vaccines and food storage, etc.

Specification

Model	RDDLZ-TDL-U06
Usage Type	Multi-use
Recording Mode	Push-To-Start or Timing Start
Communication Interface	USB 2.0
Sensor	Internal Temperature Sensor
Measuring Range	-80℃ ~ +70℃
Temperature Accuracy	±0.5℃
Temperature Resolution	0.1℃
Data Storage Capacity	32000
Logging Interval	Programmable (10s ~ 18h) [Default: 10mins]
Alarm Range	Programmable [Default: <2℃ or >8℃]
Alarm Delay	Programmable (0 ~ 960mins) [Default: 10mins]
Alam Delay	Programmable (0 ~ 254mins) [Default: 30mins]
Battery	Typically 1.5 years, ER14250 Lithium Battery (Replaceable)
Report Generation	Automatic PDF/CSV Report Generation
Software	Temp (RH) Management Software (For Windows, 21 CFR 11 Compliant)
Waterproof Level	IP65
Demension	115mm * 50mm * 20mm
Net Weight	100g

LCD Display

If there E001 or E002 on the screen, please check:

If the sensor is not connected or broken
If over the temperature detect range

Details

Applications

Tips: USB temperature data logger for vaccine storage and transportation

In the cold chain storage and transportation of vaccines and other biological products, it can ensure the quality of the vaccine and effect of immunization through monitoring the temperature of the environment in which it is located. The monitoring and management of cold chain system is an essential to ensure the quality of vaccine. Different vaccines have different requirement of environment temperature in storage and transportation. In order to ensure the safety of vaccines during storage and transportation, it must to fully automatic detect and record the ambient temperature without any human factors to improve data reliability. High quality and high precision temperature data logger can perfectly meet this requirement, because it can record data for a long time without external power supply. RDDLZ USB temperature data logger integrates temperature sensing technology, computer communication technology, solid state storage technology and database technology, which aims at the design of cold chain system to reasonably solve temperature logging problem in refrigerated storage and transportation. It can be put in cold car and cold storage any corner and automatically record temp changes in the environment. After recording, you can connect with computer’s USB port to get PDF and CSV report for data analysis.
