6" Stainless Steel Flanged Gate Valve

0 reviews • Write a review

from

$1,539.59

Ex Tax: $1,539.59

Stock: In Stock
Model: RDDLZ-FGV-DN150
Weight: 1.00
SKU: RDDLZ-FGV-DN150

Available Options

Short Description

Working Pressure

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

6 inch ss flanged gate valve features an Outside Screw and Yoke (OS&Y) design, ensuring easy identification of its status – open or closed. Constructed from durable stainless steel, this high pressure DN150 gate valve exhibits corrosion resistance and longevity. Its full bore design allows unobstructed flow, minimizing pressure drop across the system.

Specification

Model: RDDLZ-ANSI-DN150
Connection Type: Flanged Type
Flanged Port Size: 6 inch (DN150)
Working Pressure (Optional): CLASS150/300
Working Temperature: -425℃
Valve Body Material: Stainless Steel
Applicable Media: Water, Chemical, Petroleum, Gas, etc.

Detail & Dimension

Number	Part Name	Material
1	Body	CF8
2	Disc	CF8
3	Steam	304 Stainless Steel
4	Gasket	PTFE
5	Bonnet	CF8
6	Bolt	304 Stainless Steel
7	Nut	304 Stainless Steel
8	Packing	PTFE
9	Clevis Pin with Head	304 Stainless Steel
10	Split Pin	304 Stainless Steel
11	Gland	CF8
12	Eye Bolts	304 Stainless Steel
13	Flat Pad	304 Stainless Steel
14	Nut	304 Stainless Steel
15	Steam Nut	Bronze
16	Bonnet Nut	304 Stainless Steel
17	Handwheel	WCB
18	Round Nut	304 Stainless Steel

Working Pressure	Nominal	Diameter	L	d	D2	D1	D	b	f	n-φd1	H	W
CLASS150	DN150	6 inch	267	150	216	241.3	280	23.9	2	8-22	686	350
CLASS300	DN150	6 inch	403	150	216	270	320	35	2	12-22	695	350

Tips: What is a flanged gate valve?

A flanged gate valve is a type of industrial valve designed to control the flow of fluids in a piping system. It consists of a gate (a flat or wedge-shaped barrier) that can be raised or lowered to either block or allow the passage of fluid through the valve. The term "flanged" refers to the valve's connection points, which have flanges that can be bolted to corresponding flanges on the pipeline. This flange design provides a secure and leak-tight connection.
Flanged gate valves are commonly used in applications where on/off control of fluid flow is required, such as in water treatment plants, oil and gas pipelines, and various industrial processes. The flanged connections facilitate easy installation and maintenance, making them a popular choice in large-scale and critical systems where reliability and durability are essential.
