1/2" Stainless Steel Flanged Gate Valve

0 reviews • Write a review

from

$495.69

Ex Tax: $495.69

Stock: In Stock
Model: RDDLZ-FGV-DN15
Weight: 1.00
SKU: RDDLZ-FGV-DN15

Available Options

Short Description

Working Pressure

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Note: This gate valve cannot be used for drinking water.

1/2 inch ss flanged gate valve features an Outside Screw and Yoke (OS&Y) design, ensuring easy identification of its status – open or closed. Constructed from durable stainless steel, this DN15 gate valve exhibits corrosion resistance and longevity. Its full bore design allows unobstructed flow, minimizing pressure drop across the system.

Specification

Model: RDDLZ-ANSI-DN15
Connection Type: Flanged Type
Flanged Port Size: 1/2 inch (DN15)
Working Pressure (Optional): CLASS150/300
Working Temperature: -425℃
Valve Body Material: Stainless Steel
Applicable Media: Water, Chemical, Petroleum, Gas, etc.

Detail & Dimension

Number	Part Name	Material
1	Body	CF8
2	Disc	CF8
3	Steam	304 Stainless Steel
4	Gasket	PTFE
5	Bonnet	CF8
6	Bolt	304 Stainless Steel
7	Nut	304 Stainless Steel
8	Packing	PTFE
9	Clevis Pin with Head	304 Stainless Steel
10	Split Pin	304 Stainless Steel
11	Gland	CF8
12	Eye Bolts	304 Stainless Steel
13	Flat Pad	304 Stainless Steel
14	Nut	304 Stainless Steel
15	Steam Nut	Bronze
16	Bonnet Nut	304 Stainless Steel
17	Handwheel	WCB
18	Round Nut	304 Stainless Steel

Working Pressure	Nominal	Diameter	L	d	D2	D1	D	b	f	n-φd1	H	W
CLASS150	DN15	1/2 inch	108	15	35	60.3	90	8	2	4-16	178	120
CLASS300	DN15	1/2 inch	140	15	35	66.7	95	12.7	2	4-16	182	120

Tips: How to select the appropriate flanged gate valve for a specific application?

Selecting the appropriate flanged gate valve involves considering several key factors. First, assess the fluid characteristics, including pressure, temperature, and composition. Choose a valve with a pressure rating and temperature range that aligns with the application. Consider the material compatibility to ensure resistance to corrosion or erosion. Evaluate the size of the valve based on the flow requirements. Additionally, assess the operation type—whether it's manual or automated, and select a valve with a suitable actuator if needed. Check the valve's design standards to ensure it meets industry requirements. Lastly, factor in any specific application considerations, such as special coatings for harsh environments. A comprehensive understanding of these factors will guide you in choosing a flanged gate valve that effectively meets the demands of your specific application.
