50A/100A 3-12S Electronic Speed Controller (ESC) For Dual BLDC Motor

0 reviews • Write a review

from

$644.82

Ex Tax: $644.82

Stock: In Stock
Model: RDDLZ-ESC-100-312D
Weight: 1.00
SKU: RDDLZ-ESC-100-312D

Available Options

Textarea

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

High quailty electronic speed controller is used for dual BLDC motor, current continuous unilateral 50A, peak bilateral 400A, voltage 8V-60V (3-12S). Cheap ESC controller can automatically help stabilize your car when it detects a momentary loss of control, widely used in remote control and vehicle applications.

Specifications

Model: RDDLZ-ESC-D50A
Voltage: 8V-60V (3-12S)
Firmware: Latest firmware version
Power Current: 50A continuous/200A peak
Signal: PWM input
Communication Port: USB, CAN, UART
Control Modes: BLDC, FOC
Size: 84.1mmx121mmx22.6mm
Switch Off: Fireproof flower/intelligent version of fireproof flower switch
Input Source: PPM, analog, NRF, NYKO, KAMA, NUNCHUCK
Support Sensor: ABI, HALL, AS 5047, AS5048A

Dimension (Unit: mm)

Wiring diagram

Tips: How to choose the parameters of the 3-12S ESC controller?

The latest version simplifies many steps, you only need to fill in some parameters corresponding to the type of battery, the number of battery sections, whether the motor is inner rotor or outer rotor, whether it is a contour motor or belt motor, and the gear ratio of the belt motor; after the first selection is completed, the system will automatically match the corresponding parameters, you only need to adjust according to your personal preference. You only need to adjust the starting force according to your personal preference to complete the tuning.
