4" Stainless Steel Wafer Ball Valve

0 reviews • Write a review

from

$477.39

Ex Tax: $477.39

Stock: In Stock
Model: RDDLZ-WBV-DN100
Weight: 1.00
SKU: RDDLZ-WBV-DN100

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Note: This ball valve cannot be used for drinking water.

RDDLZ 4 inch (100mm) wafer style ball valves are commonly used in water treatment, HVAC, oil and gas, and chemical processing, due to their reliability, ease of installation, and efficient flow control capabilities.

Specification

Model: RDDLZ-Q71F-PN16-DN100
Type: Wafer Type Flanged Ball Valve
Port Size: 4 inch (DN100)
Body Material: 304 Stainless Steel
Ball Material: 304 Stainless Steel
Stem Material: 304 Stainless Steel
Sealing Material: PTFE
Gland Packing: PTFE
Nominal Pressure: 1.6Mpa
Strength Testing Pressure: 2.4Mpa
Seat Testing Pressure: 0.6Mpa
Applicable Media: Water, Oil, Gas
Applicable Temperature: -20℃~180℃

Dimension (Unit: mm)

Size	DN	d	D	D1	D2	T	f	H	L±1.5	W	Hole Quantity & Diameter
DN100	100	89	214	180	158	18	2	102	137	293	8-φ16

Main Parts Materials

No.	Part Name	Material	Quantity
1	Body	SS304	1
2	Cap	SS304	1
3	Seat	PTFE	2
4	Ball	SS304	1
5	Stem Washer	PTFE	1
6	Packing	PTFE	1
7	Stem	SS304	1
8	Gland	SS304	1
9	Nut	SS304	2
10	Handle	SS304	1
11	Handle Cover	PVC	1

Tips: What is a wafer ball valve?

A wafer ball valve is a type of industrial valve designed for controlling the flow of fluids in pipelines. It features a ball with a hole through its center, which can be rotated to either allow or block the flow of the fluid. The ball valve is compact, lightweight design that fits between flanges without the need for additional support. These valves are commonly used in applications where space and weight considerations are crucial. The ball inside the valve is typically made of metal, and its rotation is controlled by a handle or actuator. Wafer ball valves are known for their simplicity, reliability, and ease of installation, making them popular in various industries such as petrochemical, chemical, and water treatment.
