32 amp miniature circuit breaker (MCB) with double pole is designed to provide reliable overload and short-circuit protection in electrical circuits. This mini circuit breaker is commonly used for branch circuit protection in residential settings, ensuring the safety of wiring and connected devices.

Double Pole MCB Breaker Information

• Rated Current: 32 amp
• Rated Voltage: 230/400V AC, 50Hz
• Number of poles: 2 poles
• 6 kA rated short-circuit breaking capacity
• Compliant with IEC standard
• C curve trip characteristic
• With overload protection and short circuit protection function

Technical Data

Double Pole MCB Breaker Dimensions (Unit: mm)

Details

Tips: Difference between the circuit breaker and air switch

1. Voltage level: As to the low-voltage apparatus, the air switch is equivalent to the circuit breaker. As to the apparatus with a voltage grade below 500V, when there is a short circuit, the current can be cut off. In the high-voltage apparatus, the two are different. The circuit breaker can operate normally in various voltages above 220V. Its sustained load and short-circuit current are higher. However, the air switch will be cut off automatically if the current exceeds a certain value.
2. Arc extinguishment means: The air switch extinguishes the arc with air as the medium. Therefore, it is also named the air-type low-voltage circuit breaker. Because it has convenient operation and high safety, it is widely used. The circuit breaker has many arc extinguishing means. So, its arc extinguishing capacity is strong. The high-voltage apparatus usually employs the vacuum, sulfur hexafluoride for arc extinguishing.
3. The effects: The air switch usually plays the role of “isolation” and “protective equipment” in the small-current circuit. In the condition of short-circuit current and high current, the circuit breaker trips automatically. In the high-voltage and high-current circuit, it is normally used as the operating apparatus for powering off, powering on, connecting, and disconnecting the load.
