10 Amp 2 Pole Miniature Circuit Breaker

0 reviews • Write a review

from

$62.69

Ex Tax: $62.69

Stock: In Stock
Model: RDDLZ-MCB-2P10
Weight: 1.00
SKU: RDDLZ-MCB-2P10

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

10 amp 2 pole miniature circuit breaker (MCB) is a switch used in residential and commercial electrical systems for protecting circuits from overloads and short circuits. This mini circuit breaker provides reliable protection by automatically disconnecting the circuit if the current exceeds the safe limit, preventing potential damage to electrical equipment and wiring.

Double Pole MCB Breaker Information

Rated Current: 10 amp
Rated Voltage: 230/400V AC, 50Hz
Number of poles: 2 poles
6 kA rated short-circuit breaking capacity
Compliant with IEC standard
C curve trip characteristic
With overload protection and short circuit protection function

Technical Data

Model		RDDLZ-NB8-632PC10
Rated Current		10A
Rated Voltage		230/400V
Frequency		50Hz
Number of Poles		2P
Mechanical Life		20000 Times
Electrical Life		10000 Times
Rated Short-Circuit Breaking Capacity		6000A
Operating Short-Circuit Breaking Capacity		6000A
Rated Impulse Withstand Voltage (1.2/50)		6kV
Dielectric Test Voltage		2000V (50Hz, 1 min)
Heat & Humidity Resistance		28 Cycles
Vibration Resistance		No Obvious Vibration and Impact
Terminal Block	Terminal Block Type	Pillar Terminal Block
	Min. Terminal Size Acceptability	1mm²
	Max. Terminal Size Acceptability	25mm²
	Standard Connection Torque	2 N.m
	Max. Tolerable Torque	2.5 N.m
	Wire Insertion Depth	13mm
Reference Temperature		30℃
Operating Temperature		-35℃~+70℃
Storage Temperature		35℃~+85℃
Applicable Altitude		2000m
Tripping Mode		Thermal Magnetic Trip
Electromagnetic Tripping Type		Type C (5In-10In)
Shell Flame Retardant Grade		V0
Wire Entry Method		Both Upper and Lower
Installation Method		TH35-7.5 Standard Rail
Protection Level	Direct Installation	IP20B
	Installed in the Distribution Box	IP40B

Double Pole MCB Breaker Dimensions (Unit: mm)

Details

Tips: Difference between MCB and RCCB

An MCB (Miniature Circuit Breaker) and an RCCB (Residual Current Circuit Breaker) serve different protective functions in electrical systems.

MCB (Mini Circuit Breaker): MCBs are designed to protect circuits from overcurrent conditions, such as overloads or short circuits. They automatically cut off the power when the current exceeds a safe limit, preventing potential damage to the wiring or equipment.

RCCB (Residual Current Circuit Breaker): RCCBs protect against electrical shocks and earth leakage by detecting the difference in current between the live and neutral wires. If this difference occurs (indicating leakage), the RCCB immediately disconnects the power, ensuring safety against electric shock.
