Use a 2 amp 2 pole miniature circuit breaker in a low voltage electrical network. RDDLZ mini MCB breaker is more sensitive to overcurrent and a reliable way to protect conductors.

Double Pole MCB Breaker Information

• Rated Current: 2 amp
• Rated Voltage: 230/400V AC, 50Hz
• Number of poles: 2 poles
• 6 kA rated short-circuit breaking capacity
• Compliant with IEC standard
• C curve trip characteristic
• With overload protection and short circuit protection function

Technical Data

Double Pole MCB Breaker Dimensions (Unit: mm)

Details

Tips: The main components of the miniature circuit breaker

A miniature circuit breaker (MCB) is a crucial safety device in electrical circuits, designed to automatically disconnect the circuit in the event of overload or short circuit. Its main components include:

• Frame: The outer casing that houses all the components, made from insulating materials to prevent electrical contact.
• Contact System: Includes moving and fixed contacts that open and close the circuit. When a fault occurs, the contacts separate to interrupt the flow of electricity.
• Trip Mechanism: This includes two types—thermal and magnetic. The thermal trip uses a bimetallic strip that bends with heat caused by an overload, while the magnetic trip uses an electromagnet to react to the sudden surge of current during a short circuit.
• Arc Chute: A device used to quench the electrical arc formed when the contacts separate, preventing the arc from damaging the micro circuit breaker and ensuring safe operation.
• Terminal Block: The points where the mini MCB connects to the incoming and outgoing electrical circuits.
