3" Stainless Steel Wafer Ball Valve

0 reviews • Write a review

from

$379.69

Ex Tax: $379.69

Stock: In Stock
Model: RDDLZ-WBV-DN80
Weight: 1.00
SKU: RDDLZ-WBV-DN80

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Note: This ball valve cannot be used for drinking water.

3 inch (80mm) wafer type ball valve is a type of quarter-turn valve with a full port design that indicates the bore of the ball is larger, minimizing flow restrictions and maximizing flow capacity.

Specification

Model: RDDLZ-Q71F-PN16-DN80
Type: Wafer Type Flanged Ball Valve
Port Size: 3 inch (DN80)
Body Material: 304 Stainless Steel
Ball Material: 304 Stainless Steel
Stem Material: 304 Stainless Steel
Sealing Material: PTFE
Gland Packing: PTFE
Nominal Pressure: 1.6Mpa
Strength Testing Pressure: 2.4Mpa
Seat Testing Pressure: 0.6Mpa
Applicable Media: Water, Oil, Gas
Applicable Temperature: -20℃~180℃

Dimension (Unit: mm)

Size	DN	d	D	D1	D2	T	f	H	L±1.5	W	Hole Quantity & Diameter
DN80	80	71	194	160	138	18	2	100	115	224	8-φ16

Main Parts Materials

No.	Part Name	Material	Quantity
1	Body	SS304	1
2	Cap	SS304	1
3	Seat	PTFE	2
4	Ball	SS304	1
5	Stem Washer	PTFE	1
6	Packing	PTFE	1
7	Stem	SS304	1
8	Gland	SS304	1
9	Nut	SS304	2
10	Handle	SS304	1
11	Handle Cover	PVC	1

Tips: How to install a wafer ball valve?

To install a wafer ball valve, start by ensuring the pipeline is clean and free of debris. Position the valve between flanges, aligning the bolt holes. Place the gaskets on each side of the valve, ensuring a proper seal. Insert bolts through the holes and tighten them evenly to secure the valve in place. Check the alignment to avoid any misalignment issues. Once properly positioned, torque the bolts according to the manufacturer's specifications. Verify that the valve operates smoothly and check for any leaks. Finally, conduct a pressure test to ensure the valve's integrity.
