3/4" Stainless Steel Globe Valve

0 reviews • Write a review

from

$112.19

Ex Tax: $112.19

Stock: In Stock
Model: RDDLZ-GV-34SSGV
Weight: 1.00
SKU: RDDLZ-GV-34SSGV

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Working temperature of this type globe valve between -20 ℃ and 260 ℃. Globe control valve can be used in machinery and petrochemical industry.

Features:

Simple and compact appearance.
NPT threaded connection for easy installation of pressure gauge and pipe.
304 stainless steel has the characteristics of corrosion resistance and high temperature resistance.

Specification:

Model: RDDLZ-HNV-N12MF
Port Size: 3/4 inch
Structure: inner and outer thread
Pressure: 0-6000 psi
Temperature: -20 ℃ ~ + 260 ℃
Medium: oil, water, steam

Dimension (Unit: mm)

Model	T	L	S	A	B
HNV-N12MF	NPT 3/4"	75	38	109	50

Tips: Globe Valve Troubleshooting

The pipe is not tightly closed. Now remove the solder at the welding seam of the stop valve pipe joint and the globe valve body, unscrew the stop valve, remove the internal dirt, and then solder the pipe joint and the valve body.
Leakage at valve stem. You can first tighten the filler gland screw to see if it leaks. To avoid the difficulty of rotating the valve stem after the packing gland screw is tightened, loosen the packing gland screw for half a turn or one turn, turn the valve stem to a certain Angle, and then tighten the packing gland screw.
