15 Hp VFD, 1-Phase 220V To 3-Phase 380V VFD

0 reviews • Write a review

from

$1,587.36

Ex Tax: $1,587.36

Stock: In Stock
Model: GK3000-CS0110G
Weight: 1.00
SKU: GK3000-CS0110G

Available Options

Short Description

Input Voltage (Single Phase)

Output Voltage (Three phase)

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

15 hp (11 kW) variable frequency drive, 1-phase 220v to 3-phase 380v VFD, 25 amps, IP20, RS485 enabled.

Specification:

Basics	Model	GK3000-CS0110G
	Capacity	15 hp (11 kW)
	Shipping weight	8 kg
	Dimension	330200200 mm
	Installation size	316*188 mm
I/O Feature	Rated current	25 A
	Input voltage	1 phase 220~240V AC
	Input frequency	50Hz/ 60Hz
	Output voltage (Optional)	3 phase AC 380V/ 400V/ 415V/ 440V/ 460V (Note: 440V, 460V output voltage only for the 1-phase 240V input VFD)
	Output frequency	0Hz~1000Hz
	Over load capacity	150% of rated current for 1 minute, 180% of rated current for 3 seconds
Control Feature	Control mode	V/F control; Sensorless vector control;
	Communication	RS485
	Speed regulation	1:100
	Start torque	150% of rating torque at 1 Hz
	Speed control accuracy	≤±0.5% of rating synchronous speed
	Frequency precision	Digital setting: max frequency x± 0.01%; Analog setting: max frequency x± 0.2%
	Frequency resolution	Analog setting: 0.1% of max frequency; Digital setting: 0.01Hz
	Torque boost	Automatic torque boost, manual torque boost 0.1%~30.0%
	Interior PID controller	Be convenient to make closed-loop system
	Automatic energy save running	Optimize V/F curve automatically based on the load to realize power save running
	Automatic voltage regulation (AVR)	Can keep constant output voltage when power source voltage varies.
	Automatic current limiting	Limit running current automatically to avoid frequent over-current which will cause trip
Environment	Enclosure rating	IP 20
	Temperature	–10℃~ +40℃; VFD will be derated if ambient temperature exceed 40℃; each rise 1℃, the derate will be 5%
	Humidity	5%-95%, without condensation
	Altitude	≤1000m; VFD will be derated if above 1000m
	Impingement and oscillation	Normal running:<5.9m/s2 (0.6g); Transportation:<15m/s2 (1.5g)
	Store environment	–20℃~ +60℃; no dust, no corrosive gas, no direct sunlight

Note: RDDLZ VFD Cannot be used as a power source, it Can only be directly connected to an induction motor to control the motor speed.

Tips: Single phase 220V to three phase 380V VFD features

Product features

1-phase 220V input to 3-phase 380V output VFD adopts AC-DC circuit structure and uses SPWM modulation control technology to convert ordinary 1-phase 220V power to industrial 3-phase 380V power. It is suitable for 3-phase asynchronous motors with an output phase angle of 120°, which fully satisfies the motor use standard and is suitable for all types of motor loads. The single phase to three phase VFD solves the inconvenience of production in some areas due to 3-phase power restrictions, and also solves the needs of some users who cannot apply to 3-phase power due to site restrictions.

Technical features

Ordinary utility 220V input, eliminating the cumbersome procedures of applying for 3-phase power and various labor costs and various hidden costs.
The output uses industrial 3-phase power, but is billed according to the civilian 1-phase power, which is economical.
Core components are imported devices, stable performance, long service life.
Safe and reliable, the input 1-phase power and output 3-phase power completely electrical isolation.
Input wide voltage range design, to adapt to the work environment of the general low utility voltage in various regions.
Output protection function is perfect, there are over-voltage, overload, over temperature, short circuit, over current and other kinds of protection.
