1 Hp VFD, 1-Phase 220V To 3-Phase 380V VFD

0 reviews • Write a review

from

$309.15

Ex Tax: $309.15

Stock: In Stock
Model: GK3000-CS0007
Weight: 1.00
SKU: GK3000-CS0007

Available Options

Short Description

Input Voltage (Single Phase)

Output Voltage (Three phase)

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Best 1 hp (0.75 kW) variable frequency drive, single phase 220v to three phase 380v VFD for AC motor speed control, 400v/ 415v output for choice.

Specification:

Basics	Model	GK3000-CS0007
	Capacity	1 hp (0.75 kW)
	Shipping weight	3 kg
	Dimension	236130176 mm
	Installation size	222*116 mm
I/O Feature	Rated current	2.1 A
	Input voltage	1 phase 220~240V AC
	Input frequency	50Hz/ 60Hz
	Output voltage (Optional)	3 phase AC 380V/ 400V/ 415V/ 440V/ 460V (Note: 440V, 460V output voltage only for the 1-phase 240V input VFD)
	Output frequency	0Hz~1000Hz
	Over load capacity	150% of rated current for 1 minute, 180% of rated current for 3 seconds
Control Feature	Control mode	V/F control; Sensorless vector control;
	Communication	RS485
	Speed regulation	1:100
	Start torque	150% of rating torque at 1 Hz
	Speed control accuracy	≤±0.5% of rating synchronous speed
	Frequency precision	Digital setting: max frequency x± 0.01%; Analog setting: max frequency x± 0.2%
	Frequency resolution	Analog setting: 0.1% of max frequency; Digital setting: 0.01Hz
	Torque boost	Automatic torque boost, manual torque boost 0.1%~30.0%
	Interior PID controller	Be convenient to make closed-loop system
	Automatic energy save running	Optimize V/F curve automatically based on the load to realize power save running
	Automatic voltage regulation (AVR)	Can keep constant output voltage when power source voltage varies.
	Automatic current limiting	Limit running current automatically to avoid frequent over-current which will cause trip
Environment	Enclosure rating	IP 20
	Temperature	–10℃~ +40℃; VFD will be derated if ambient temperature exceed 40℃; each rise 1℃, the derate will be 5%
	Humidity	5%-95%, without condensation
	Altitude	≤1000m; VFD will be derated if above 1000m
	Impingement and oscillation	Normal running:<5.9m/s2 (0.6g); Transportation:<15m/s2 (1.5g)
	Store environment	–20℃~ +60℃; no dust, no corrosive gas, no direct sunlight

Note: RDDLZ VFD Cannot be used as a power source, it Can only be directly connected to an induction motor to control the motor speed.

Tips: Why you need a 1-phase 220V to 3-phase 380V VFD?

Due to national policies and regional restrictions, many areas will now withdraw 3-phase 380V industrial power. No 3-phase power in the region to apply for 3-phase power cumbersome procedures and a variety of labor costs and various hidden costs, resulting in some areas can not use industrial 380V power. and general industrial equipment, such as AC motors are mostly 3-phase 380V, in the absence of 3-phase electricity can not run. We can only find ways to convert 1-phase 220V to 3-phase 380V. However, many single phase 220V to three phase 380V equipment on the market are ridiculously expensive, so many users in need are discouraged. And the original machine can only be temporarily placed, or put into other places with industrial electricity to use.

RDDLZ offers a series of 1-phase 220V input to 3-phase 380V output variable frequency drive from 1hp to 20 hp, which can drive 3-phase asynchronous motor soft start operation, for infinitely adjustable speed. The input power only needs single phase 220V, output three phase 380V, and the price is acceptable to most users. Our VFDs are about 1/10 of the price of the booster on the market, compact size, powerful, 0-400Hz can be adjusted at will, completely solve the embarrassing situation of industrial equipment without 3-phase power.
