12V/24V DC Cooling Fan, 140mm X 140mm X 25mm

0 reviews • Write a review

from

$59.86

Ex Tax: $59.86

Stock: In Stock
Model: RDDLZ-CF-DC14025
Weight: 1.00
SKU: RDDLZ-CF-DC14025

Available Options

Short Description

Rated Voltage

Model

Interface

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

The dc cooling fan is available in either 12 or 24 volt voltage. It has a fan speed of 1000rpm/1400rpm/2000rpm and dimensions of 140mm x 140mm x 25mm, the 24V DC cooling fan has a high airflow and a long service life.

Specifications:

Model

RDDLZ-DC14025SLL

RDDLZ-DC14025BLL

RDDLZ-DC14025SLM

RDDLZ-DC14025BLM

RDDLZ-DC14025SLH

RDDLZ-DC14025BLH

Rated Voltage

12V

24V

12V

24V

12V

24V

12V

24V

12V

24V

12V

24V

Bearing Type

Oily

Ball

Oily

Ball

Oily

Ball

Rated Current

0.08A

0.05A

0.08A

0.05A

0.12A

0.07A

0.12A

0.07A

0.17A

0.18A

0.17A

0.18A

Input Power

0.96W

1.2W

0.96W

1.2W

1.44W

1.68W

1.44W

1.68W

2.04W

4.32W

2.04W

4.32W

Fan Speed

1000±10%RPM

1400±10%RPM

2000±10%RPM

Air Flow

46CFM

64CFM

91.2CFM

Static Pressure

1.7mm-H2O

2.4mm-H2O

3.5mm-H3O

Noise

24dB-A

31dB-A

37dB-A

Dimension

140mm x 140mm x 25mm

Material

Plastic

Certificate

CE, UL

Fire Rating

UL94V-0

Operating Temperature

-10 ℃ ~ 70 ℃

Operating Humidity

35% ~ 85RH

Storage Temperature

-40 ℃ ~ 70 ℃

Storage Humidity

35% ~ 85RH

Dimensions and Curves (unit: mm)

DC Cooling Fan Interface

Tips: How to install a cooling fan in the case?
The installation of the cooling fan in the chassis depends on the airflow in the heat source distribution area of the chassis. Generally, the cooling fan in the chassis is installed on the front side of the chassis. It draws strong cold air from the front side and blows it to the motherboard. Finally, the switching power supply cools the wind and the fan row Come out and produce convection.
It is best to consider the orientation of the gas fluidity. The best plan is to install a cooling fan on the front and back, in a diagonal orientation distribution area, and then the heat dissipation effect of all the cases is very good. The front fan of the case blows inside and the rear fan Blow to the outside. As one of the most important links in computer peripherals, the choice of switching power supply can be said to be crucial.
