12V/24V DC Cooling Fan, 50mm X 50mm X 15mm

12V/24V DC Cooling Fan, 50mm X 50mm X 15mm
12V/24V DC Cooling Fan, 50mm X 50mm X 15mm
0 reviews • Write a review
from
$25.79
Ex Tax: $25.79
  • Stock: In Stock
  • Model: RDDLZ-CF-DC5015
  • Weight: 1.00
  • SKU: RDDLZ-CF-DC5015

Available Options

Add to Cart
Buy Now Question?
Add to Wish List Compare this Product

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

12V/24V DC brushless cooling fan 50mm x 50mm x 15mm, IP67, fan speed of 4000rpm/4500rpm/5000rpm, fireproof and waterproof. RDDLZ brushless DC fans are a versatile and reliable cooling solution for a wide range of applications, from domestic appliances to industrial equipment.

12V/24V DC Cooling Fan Specifications:

ModelRDDLZ-DC5015SLLRDDLZ-DC5015BLLRDDLZ-DC5015SLMRDDLZ-DC5015BLMRDDLZ-DC5015SLHRDDLZ-DC5015BLH
Rated Voltage12V24V12V24V12V24V12V24V12V24V12V24V
Bearing TypeOilyBallOilyBallOilyBall
Rated Current0.06A0.07A0.060.07A0.06A0.1A0.12A0.1A0.12A
Input Power0.72W1.44W0.72W1.44W0.84W1.44W0.84W1.44W1.2W2.88W1.2W2.88W
Fan Speed4000±10%RPM4500±10%RPM5000±10%RPM
Air Flow9.7CFM10.9CFM12.4CFM
Static Pressure2.8mm-H2O3.2mm-H2O3.8mm-H3O
Noise25.5dB-A29dB-A31dB-A
Dimension50mm x 50mm x 15mm
MaterialPlastic
CertificateCE, UL
Fire RatingUL94V-0
Operating Temperature-10 ℃ ~ 70 ℃
Operating Humidity35% ~ 85RH
Storage Temperature-40 ℃ ~ 70 ℃
Storage Humidity35% ~ 85RH

Dimensions and Curves (unit: mm)
DC Cooling Fan Interface



Tips: DC cooling fan noise processing method
1. Select appropriate fan specifications and parameters according to the actual situation.
2. Regularly clean the dust and refuel the fans to reduce the conflict between the fans.
3. Put a sponge, rubber or cotton between the fan and the fixed end to reduce the noise caused by the feeling caused by the high speed rotation of the fan.
