12V 1500W Switching Power Supply

0 reviews • Write a review

from

$212.19

Ex Tax: $212.19

Stock: In Stock
Model: RDDLZ-SMPS-1500-12
Weight: 1.00
SKU: RDDLZ-SMPS-1500-12

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Cheap 1500W switching power supply (SMPS) converts AC input to a stable DC at a rated current of 120A. Quality 12V DC switch mode power supply comes with overvoltage & overload protection, strong anti-interference ability, efficient work and good performance, suitable for all kinds of electrical equipment or devices.

Specifications

Model	RDDLZ-S-1500-12
Output	DC Voltage	0~12V
	Rated Current	120A
	Rated Power	1500W
	Ripple and Noise ①	≤150mV
	Voltage Accuracy	±1%
	Output Voltage Adjustment Range	±10%
	Load Regulation	＜±0.5
	Linear Adjustment Rate	＜±1%
Input	Voltage Range	180~264V AC 47Hz~63Hz; 254V DC~370V DC
	Efficiency (Typical) ②	＞85%
	Working Current	220V AC, 13.5A
	Electric Shock	60A 230V AC
	Start, Rise, Hold Time	800ms, 50ms, 20ms; 230V AC
Protection	Overload Protection	105%~135% Type: constant current output +VO drops to the undervoltage point and cuts off the output; Reset: power on again
Protection	Over Temperature Protection	RTH3: The fan rotates continuously, and the output is turned off when >90℃.
Environment	Temperature & Humidity	-10C~+50℃; 20%~90RH
Environment	Storage Humidity	-20C~+85℃; 10%~95RH
Safety & EMC	Withstand Voltage	Input-Output: 1.5kV AC; Input-Enclosure: 1.5kV AC; Output-Enclosure: 0.5kV AC
	Leakage Current	Input-Output: <6mA at 1.5kV AC
	Leakage Current	Input-Output: <1.5mA at 220V AC
	Isolation Resistor	Input-Output, Input-Enclosure, Output Enclosure: 500V DC/100MΩ
Size	292x133x70mm
Net Weight	2.7kg

Features

High-quality capacitors: 12V switching power supply uses high-quality electrolytic capacitors, which have large capacity, low loss, and are more durable and safer.
Pure copper transformer: It is equipped with sufficient turns of coil winding, with reliable performance, full power and stable operation.
EML filter: RDDLZ 1500W switch mode power supply has strong anti-interference ability, efficient work and good performance.

Details

Dimension (Unit: mm)

SMPS Power Supply Applications

Power Tools: Electric Saw, Drilling Machine, Ginder, Sand Blast Machine, Punching Machine, Weeding Machine, Air Compressor, etc.
Office Devices: Computer, Printer, LCD Monitor, Scanning Machine, etc.
Electrics & Household Appliance: TV, VCRS, Radio, Dust Collector, Fan Lamp or LED Strip, Sewing Machine, Microwave Oven, Fridge/Freezer, Coffemarker, etc.
Industrial Equipment: Monitoring Equipment, Shipping, Vehicle, Metal halide Lamp, Solar System, Wind Power Generation, etc.

Tips: What types of devices or applications require a 12V 1500W power supply?

A 12V 1500W switching power supply is crucial for a range of applications requiring a stable and high-power 12-volt DC source. It is commonly found in industrial machinery, telecommunications equipment, and data centers where it ensures uninterrupted operations. In industrial settings, it powers manufacturing equipment, conveyors, and automation systems. Telecommunications infrastructure, including base stations and network devices, relies on these power supplies for consistent connectivity. Data centers use them to support servers, storage systems, and networking equipment, ensuring efficient data processing and storage.

Additionally, high-end computing systems, such as gaming computers and workstations with powerful CPUs and GPUs, depend on 12V 1500W power supplies to meet their demanding energy needs. Large-scale LED lighting installations, like stadium lighting and architectural displays, benefit from these power supplies for their high luminosity requirements. Lastly, audio equipment, including high-power amplifiers in concert venues and studios, employs 12V 1500W power supplies for quality sound reproduction and amplification.
