1/8 Inch Stainless Steel Needle Valve, DN6

0 reviews • Write a review

from

$59.52

Ex Tax: $59.52

Stock: In Stock
Model: RDDLZ-NV-DN6
Weight: 1.00
SKU: RDDLZ-NV-DN6

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Note: This needle valve cannot be used for drinking water.

RDDLZ stainless needle valve is a compact 2-way stainless steel needle valve with 1/8 inch threads. This valve can be used as a reliable shut-off valve, or to accurately control (relatively low) flow rates of clean gases or fluids.

Specification

Model: RDDLZ-NV-DN6
Size: 1/8 inch
Connection thread size: DN6
Needle valve diameter: 3mm
Nominal pressure: 16 MPa
Material: 304 Stainless Steel
Working pressure: ≤420 bar
Working temperature: -20~180℃
Installation method: Screw connection
Medium: Gas, liquid

Features

Smooth and accurate flow control
With a very compact design and reliable leak tight shut off
High pressures up to 6000 psi
Wide temperature range from -20 up to 180°C.
Suited for aggressive fluids thanks to the 304 stainless steel

Dimension

Model	A	B	C	D
RDDLZ-NV-DN6	40mm	70mm	22mm	3mm

Stainless Steel Needle Valve Application

Tips: What is a needle valve？

Needle valves, sometimes referred to as plunger valves, are regulating valves and enable engineers to finely control and regulate water flow and pressure. The precision is achieved through the fine movement of the shaft, which enables the gearbox to move the piston tube in a sliding motion towards the opening or closing position, depending on the requirements of the control system.
