0~100 Psi Pressure Gauge, 0 To 7 Bar

0 reviews • Write a review

from

$48.56

Ex Tax: $48.56

Stock: In Stock
Model: RDDLZ-PG-100
Weight: 1.00
SKU: RDDLZ-PG-100

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Note: This pressure gauge cannot be used for drinking water.

Buy a 0 to 100 psi pressure gauge from RDDLZ to help measure water pressure, hydraulic pressure, oil pressure and air pressure. Best pressure gauge provides a dual-scale display, 0~7 bar measuring range, 40mm dial diameter, stainless steel materials, 1/8" BSPT thread specification, waterproof, perfect for pressure detection in metallurgy, electric power, petroleum and chemical industry.

Specifications

Model: RDDLZ-TS-Y408-100psi
Dial Diameter: φ40mm
Installation Method: Radial
Range: 0~100 psi, 0~6 bar
Installation Diameter: 1/8
Thread Specification: BSPT
Size: 6x4x2.5cm
Material: Stainless Steel
Package Size: 8.5x6.5x4.5cm
Product Weight: 44g
Package Weight: 60g

Features

0 to 100 psi pressure gauge can be used as a water pressure gauge, air pressure gauge, hydraulic pressure gauge and oil pressure gauge.
RDDLZ pressure gauge equipped with dual scale (0~15 psi/0~1 bar), and a lower-mount male connection with a 1/8" BSPT thread.
The circular dial is enclosed in a stainless steel case for corrosion resistance, portable 0~1 bar pressure gauge offers clear readings and is weather-resistant.
Display accuracy of 2.5% over the entire range of the gauge.
Brass and stainless steel wetted parts for measuring non-corrosive liquid and gas pressure. Such as water, oil, fuel, coolant, air, co2, nitrogen, and argon pressure test.

Dimension (Unit: mm)

Details

Applications

Pressure gauge is the most commonly used measuring instrument for displaying and controlling pressure, widely used in the chemical industry, petroleum, metallurgy, mining, and electric power production, especially in vehicle maintenance shops, heat pipe networks, water and gas supply systems, etc.

Tips: What is a diaphragm pressure gauge?

RDDLZ 0 to 300 psi pressure gauges are all diaphragm pressure gauges. Diaphragm pressure gauges are suitable for measuring the pressure or negative pressure of various fluid media with certain corrosiveness, non-solidification or non-crystallization, and the corrosion resistance depends on the diaphragm material.
