0~160 Psi Pressure Gauge, 0 To 11 Bar

0 reviews • Write a review

from

$48.76

Ex Tax: $48.76

Stock: In Stock
Model: RDDLZ-PG-160
Weight: 1.00
SKU: RDDLZ-PG-160

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Note: This pressure gauge cannot be used for drinking water.

0 to 160 psi pressure gauge is a highly accurate and compact diaphragm pressure gauge for measuring water pressure, hydraulic pressure, oil pressure and air pressure, widely used in mining, smelting, medical treatment, maintenance, etc. Low price pressure gauge features a dual-scale display, 0~11 bar measuring range, 40mm dial diameter, stainless steel materials, and 1/8" BSPT thread specification.

Specifications

Model: RDDLZ-TS-Y408-160psi
Dial Diameter: φ40mm
Installation Method: Radial
Range: 0~160 psi, 0~11 bar
Installation Diameter: 1/8
Thread Specification: BSPT
Size: 6x4x2.5cm
Material: Stainless Steel
Package Size: 8.5x6.5x4.5cm
Product Weight: 44g
Package Weight: 60g

Features

0 to 160 psi pressure gauge can be used as a water pressure gauge, air pressure gauge, hydraulic pressure gauge and oil pressure gauge.
RDDLZ pressure gauge equipped with dual scale (0~15 psi/0~1 bar), and a lower-mount male connection with a 1/8" BSPT thread.
The circular dial is enclosed in a stainless steel case for corrosion resistance, portable 0~1 bar pressure gauge offers clear readings and is weather-resistant.
Display accuracy of 2.5% over the entire range of the gauge.
Brass and stainless steel wetted parts for measuring non-corrosive liquid and gas pressure. Such as water, oil, fuel, coolant, air, co2, nitrogen, and argon pressure test.

Dimension (Unit: mm)

Details

Applications

Pressure gauge is the most commonly used measuring instrument for displaying and controlling pressure, widely used in the chemical industry, petroleum, metallurgy, mining, and electric power production, especially in vehicle maintenance shops, heat pipe networks, water and gas supply systems, etc.

Tips: Bar and Psi of a pressure gauge?

The bar of the pressure gauge is an imperial pressure unit, which is a unit of tire pressure, and psi is a pressure unit, which is commonly used in Europe, America and other countries. 0~300 psi and 0~20 bar pressure gauges are available on sisco.com.
