Garden Hose Quick Connect, Male Connector, M Type

0 reviews • Write a review

from

$3.44

Ex Tax: $3.44

Stock: In Stock
Model: RDDLZ-QC-M01
Weight: 1.00
SKU: RDDLZ-QC-M01

Available Options

Short Description

Input Cannula Diameter

Output Cannula/Thread Diameter (03)

Output Cannula/Thread Diameter (04)

Output Cannula/Thread Diameter (06)

Output Cannula/Thread Diameter (23)

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Low price quick connector for sale online. Fast connector with a male connector is designed for water and air. It is also an M-type quick-connect coupling that has 03/04/06/23mm input cannula diameters for selection, and can quickly connect to the hose without tools.

Specifications

Model	RDDLZ-KJH
Fluid	Air/Water
Material	Brass
Maximum operating pressure	1.0MPa
Operating vacuum pressure	-100kPa
Proof pressure	3.0MPa
Ambient and fluid temperature	Air:-5~60°C, Water:0~40°C
Tubing material	Nylon, Soft nylon, Polyurethane
Tubing O.D.	Φ3, Φ3.2, Φ4, Φ6

Quick Connector Details

Applicable tubing O.D (mm)	Model	Weight (g)
Φ3	RDDLZ-KJH03-M3	1.6
	RDDLZ-KJH03-M5	2
	RDDLZ-KJH03-M6	2.1
	RDDLZ-KJH03-01S	4.7
Φ3.2	RDDLZ-KJH23-M3	1.6
	RDDLZ-KJH23-M5	2
	RDDLZ-KJH23-M6	2.1
	RDDLZ-KJH23-01S	4.7
Φ4	RDDLZ-KJH04-M3	1.9
	RDDLZ-KJH04-M5	2.4
	RDDLZ-KJH04-M6	2.5
	RDDLZ-KJH04-01S	4.6
Φ6	RDDLZ-KJH06-M5	3.3
	RDDLZ-KJH06-M6	3.5
	RDDLZ-KJH06-01S	5.2

Tips: What is a quick connector?

A quick connector is a connector that can be connected or disconnected without tools. Quick connectors can be divided into air quick connectors, oxygen fuel gas quick connectors, gas and liquid quick connectors, oil pressure quick connectors, inert gas quick connectors, cooling water temperature oil quick connectors, and semiconductor quick connectors.
