Electric Car Jack Kit, 12V, 3.5 Ton

0 reviews • Write a review

from

$367.58

Ex Tax: $367.58

Stock: In Stock
Model: RDDLZ-EJ-CJK35
Weight: 1.00
SKU: RDDLZ-EJ-CJK35

Available Options

Lifting Range

Textarea

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Portable and powerful! 12V electric car jack kit with 3.5 tons load capacity. Intelligent control, easy lifting and lowering, time-saving and efficient. Comes with power cord, can be plugged into the car cigarette lighter. Essential for emergency rescue, portable storage bag is convenient to carry. Ensure easy maneuvering of vehicle height in any situation.

Specification

Electric Jack	Model	RDDLZ-ZSTT02
	Motor Power	150W
	Maximum Current	13A
	Operating Voltage	DC12V
	Lifting Capacity	5 ton
	Minimum Height	135mm
	Maximum Height	530mm
	Structural Characteristics	Electric Jack
	Application	Tire Changing Tools
	Load	5000kg
	Dimension	363316cm
	Lifting Range	135-360mm/155-450mm/235-530mm (optional)
	Component Net Weight	8.8/9.2kg
Metal Double Bar Inflatable Pump	Maximum Inflation Pressure	150psi
	Air Flow Rate	35L/min
	Current	10A
	Length of Inflatable Tube	0.65m
	Power Cord Length	4m
Electric Wrench	Rated Power	80W
	Operating Voltage	DC12V
	Maximum Current	13A
	Maximum Torque	480N.M
	Dimension	281011.5cm
	Wrench Net Weight	1.5kg

Dimension: (mm)

Details

Instructions for Use

Equipped with battery cable clamp and cigarette lighter plug can be directly inserted into the cigarette lighter, or connected to the car battery to get electricity.
Connect the electric jack and cigarette lighter power cord.
Place the electric jack under the chassis support of the car.
Press the UP button to raise the vehicle until the wheels leave the ground, then press the DOWN button to lower the wheels.
Stand half a meter away from the car and use the remote control to control it.
Connect the electric wrench and cigarette lighter power cord.
Select the correct socket for the model.
Loosen and remove the tire nuts one by one-using an electric wrench or a reach wrench to the corner form.

Application

Tips: How to Test an Electric Jack Kit?

First, make sure your vehicle is parked on a flat and firm surface for safety. Then, connect the power cord to an appropriate electrical outlet and make sure the jack and cable are not damaged.

Next, plug the electric jack into the vehicle's jack port and make sure the connection is secure. Start the power supply and check that the electric hydraulic car jack operates smoothly and without abnormal noise or vibration.

Using the buttons on the remote or control panel, slowly raise the jack up the vehicle. Observe the response speed and lifting height of the electric jack to ensure that it is within the normal operating range.

While the vehicle is being lifted, check for any abnormalities underneath the electric car jack to make sure there are no oil leaks or other problems. You can also test the lowering function of the jack by observing if it is able to lower the vehicle smoothly.

Finally, test the self-locking function of the electric jack to ensure that the jack stays securely at the chosen height during the lifting process. Completing these testing steps ensures that the electric car jack kit is within its normal operating range and can be used to lift vehicles safely and reliably.
