2 Amp 3 Pole Miniature Circuit Breaker

0 reviews • Write a review

from

$81.69

Ex Tax: $81.69

Stock: In Stock
Model: RDDLZ-MCB-3P02
Weight: 1.00
SKU: RDDLZ-MCB-3P02

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

3 pole miniature circuit breaker (MCB) is ideal for the protection of circuits in industrial, commercial, and residential sectors, offering reliable and efficient protection for a wide range of applications. This 2 amp micro circuit breaker ensures that circuits are quickly disconnected in the event of a fault, preventing potential damage to equipment, and wiring, and reducing the risk of electrical fires.

3 Pole MCB Breaker Information

Rated Current: 2 amp
Rated Voltage: 230/400V AC, 50Hz
Number of poles: 3 pole
6 kA rated short-circuit breaking capacity
Compliant with IEC standard
C curve trip characteristic
With overload protection and short circuit protection function

Technical Data

Model		RDDLZ-NB8-633PC02
Rated Current		2A
Rated Voltage		230/400V
Frequency		50Hz
Number of Poles		3P
Mechanical Life		20000 Times
Electrical Life		10000 Times
Rated Short-Circuit Breaking Capacity		6000A
Operating Short-Circuit Breaking Capacity		6000A
Rated Impulse Withstand Voltage (1.2/50)		6kV
Dielectric Test Voltage		2000V (50Hz, 1 min)
Heat & Humidity Resistance		28 Cycles
Vibration Resistance		No Obvious Vibration and Impact
Terminal Block	Terminal Block Type	Pillar Terminal Block
	Min. Terminal Size Acceptability	1mm²
	Max. Terminal Size Acceptability	25mm²
	Standard Connection Torque	2 N.m
	Max. Tolerable Torque	2.5 N.m
	Wire Insertion Depth	13mm
Reference Temperature		30℃
Operating Temperature		-35℃~+70℃
Storage Temperature		35℃~+85℃
Applicable Altitude		2000m
Tripping Mode		Thermal Magnetic Trip
Electromagnetic Tripping Type		Type C (5In-10In)
Shell Flame Retardant Grade		V0
Wire Entry Method		Both Upper and Lower
Installation Method		TH35-7.5 Standard Rail
Protection Level	Direct Installation	IP20B
	Installed in the Distribution Box	IP40B

3 Pole MCB Breaker Dimensions (Unit: mm)

Details

Tips: How to choose an MCB breaker?

When selecting an MCB (Miniature Circuit Breaker), consider the following factors:

Current Rating: Choose an MCB with a current rating that matches the expected load of the circuit. For example, for a 2 amp load, select a 16A MCB.
Voltage Rating: Ensure the mini circuit breaker is rated for the voltage of your system, typically 230V for residential or 400V for industrial applications.
Breaking Capacity: The micro circuit breaker should have a breaking capacity (the maximum fault current it can safely interrupt) that exceeds the potential short-circuit current in your system.
Trip Curve: MCBs have different trip curves (B, C, D). Curve B is suitable for residential circuits with resistive loads, while C is ideal for circuits with moderate inrush currents like motors.
Number of Poles: Select the number of poles based on your circuit type—single pole for single-phase or multi pole for three-phase systems.
