13 Amp 3 Pole Miniature Circuit Breaker

0 reviews • Write a review

from

$38.00

Ex Tax: $38.00

Stock: In Stock
Model: RDDLZ-MCB-3P13
Weight: 1.00
SKU: RDDLZ-MCB-3P13

Available Options

Short Description

Rated Voltage (Ue)

Trip Curve

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

3 Pole MCB Breaker Information

Model: RDDLZCLXB3-13
Rated Current: 13 amp
Rated Voltage: 230/400V AC, 50Hz/ 60Hz
Number of poles: Three pole
6 kA short circuit breaking capacity
Accordance with IEC standard
Standard 35 mm DIN rail mounting
Suitable for supplementary protection
Three levels of short-circuit protection choose from B, C or D curves

Technical Data

Standard Certifications		IEC	UL1077
Electrical Parameters	Height	86 mm
	Width	18 mm per pole
	Mounting	DIN Rail
	Rated Current (In)	1A, 2A, 3A, 4A, 6A, 10A, 13A, 16A, 20A, 25A, 32A, 40A, 50A, 63A (Available)
	Number of poles	1P, 2P, 3P, 4P (Available)
	Rated Voltage (Ue) (Optional)	240/415V or 230/400V	277/480V
	Rated Insulation Voltage (Ui)	500V
	Rated Frequency	50Hz/60Hz
	Short Circuit Interrupting Capacity (Optional)	6/10KA	5KA
	Trip Characteristic (Optional)	B Curve (3-5In)	B Curve (4In)
		C Curve (5-10In)	C Curve (7In)
		D Curve (10-20In)	D Curve (14In)
Mechanical Parameters	Electrical Life	8000 times
	Mechnical Life	10000 times
	Protection Degree	IP20
	Calibration Temperature	30℃
	Operating Temperature	-5℃~+40℃
	Storage Temperature	-25℃~+70℃
	Tightening Torque	22 Ib-in (2 Nm)
	Terminal Size Acceptability–Min/Max	2.5 mm²(12 AWG) / 25mm²(3 AWG)

3 Pole MCB Breaker Dimensions (Unit: mm)

Details

Tips: Features of miniature circuit breaker

High breaking capacity in rated short-circuit with partial rated current level above 10KA.
Double wiring function is easy to connect standard bus-bar and flexible circuit conductor.
Amphenol connector with finger touch protection with higher security.
Energy storage mechanism operation that makes touch spot open and close quickly overcomes the adverse effect caused by the speed of manual operation of the handle and improves the service life of product.
A variety of accessories are available for modular and flexible combination, which is convenient for users to install.
Shell and partial functional components are made with imported plastics that are high fire retardant, high temperature resistant and high shock resistant.
High current limiting coefficient and high cost performance.
