6000W 12V/24V/48V DC to 110V/120V/220V/230V/240V AC pure sine wave power inverter works with maximum efficiency towards most of the electronic devices like cell phone, laptops, tablets, lights, TV, computer, fan, refrigerattor, washing mashine, microwave oven etc., at home or outdoors.

Specification

Features

• 6000 Watt continuous power and 12000 Watt peak power
• Pure sine wave inverter, capable of producing clean & stable electricity
• Soft-start technology
• USB charging port for powering your phone, laptop, etc.
• Aluminum alloy casing with good heat dissipation
• Multiple protections against under and over voltage, over load, over temperature, short circuit and input polarity reverse connection
• ON/OFF switch design, easy to use
• Intelligent cooling fan, long working life

Details

Wiring Diagram

Note: The wiring of 48V inverter is similar to the 24V inverter, and the batteries are connected in series.

LCD Display (Optional)

The LCD display will show input voltage, output voltage, frequency, power, waveform, and battery capacity.

Protection Functions & Applications

• Reverse Polarity Protection: Auto protection when input positive and negative polarities are reversely connected – The fuse blown out.
• Short Circuit Protection: Automatically self-protect when short circuit occurs – Red LED light ON.
• Low Voltage Protection: Automatically protect when in low voltage – Alarm first, the voltage continuously reduces, the red light is on and the inverter shuts down.
• Over Voltage Protection: Automatically protect when in high voltage – Red LED light is on, and the inverter automatically shuts down.
• Over Temperature Protection: Automatically self-protect when at high temperature – Alarm first, the temperature continuously rises, the red light is on and the inverter shuts down.
• Overload Protection: Automatic self-protection when there is overload – Red LED light is on and the inverter automatically shuts down.

Tips: How to choose a proper power inverter for the batteries?

If a battery is 12V/50AH, we can obtain a battery output power - 600 watts via multiplying 12V by 50AH. If the inverter efficiency is 90%, then we multiply 90% by 600 watts to get 540 watts. This means that your battery can drive an inverter with an output power of up to 540 watts. Of course, you can also take a "one-step" purchasing method, that is, to select a power inverter with an output power of 800 watts, regardless of the specifications of the battery used in your car. Then, use it within the allowable range of this battery at the moment, and perhaps change a new car to use it at full power afterwards.

If your requirement for the inverter power is not high, for example, 100 watts is enough, you can buy a low-power inverter. In addition, when determining the power of the inverter, there is an important principle, that is, do not run for a long time at full load when using the inverter; otherwise it will greatly shorten the life of the inverter. At the same time, the failure rate of the inverter will also be significant rise. It is strongly recommended that users use inverters that do not exceed 85% of rated power.
