150 Watt Pure Sine Wave Power Inverter, 24V DC To 220V AC

0 reviews • Write a review

from

$96.03

Ex Tax: $96.03

Stock: In Stock
Model: RDDLZ-PI-150W
Weight: 1.00
SKU: RDDLZ-PI-150W

Available Options

Frequency

Digital Display

Input DC Voltage (V)

Output AC Voltage (V)

Output Socket

Textarea

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

150W pure sine wave power inverter provides clean and stable AC power, capable of running sensitive household devices like refrigerators and small air conditioners. Built with an aluminum shell for efficient cooling and multi-protection features, 150 watt power inverter offers both 12V/24V input options and supports customization with or without a digital display.

Note: 150W pure sine wave inverter can't power a small refrigerator.

Specification

Model	RDDLZ-JWP-150W
Input Voltage	DC12V/24V
Output Voltage	AC110V/220V
Rated Power	150W
Maximum Power	300W
Output Frequency	50/60Hz±3Hz
USB Output (optional)	5V, 500mA
Output Waveform	Pure sine wave
Protection	Overload protection, over-temperature protection, over-voltage protection, short-circuit protection, under-voltage protection, reverse voltage protection
Size	190 x 122 x 50mm
Single Weight	790g

Features

Outputs pure sine wave with less than 3% THD, delivering better or equal power quality compared to utility power.
Two LED indicators show working or protected status, with automatic restart after protection.
Includes undervoltage, overvoltage, overload, and over-temperature protection, with alarm and auto-shutdown.Improve power inverter safety
150W power inverter features a universal AC output socket and an optional USB interface.
Copper terminals for excellent conductivity, improving power inverter conversion efficiency.

Details

AC Output: Receptacle according to user selection. 12V/24V DC to 110V/220V AC (±10%).
Signal Indicator: Green light indicates normal operation, red light indicates fault indication.
USB Output (optional): DC output mode 1A/5V.
Power On/Off Switch: I is to start working, O is to stop working.
Positive Terminal: Connect with the positive terminal of the battery.
Negative Terminal: Connect with the negative terminal of the battery.
Intelligent Fan: Intelligently turn on and off according to the power inverter's temperature and load condition, energy saving and high efficiency.

Connection Diagram

Dimension (Unit: mm)

Application

Tips for Using the 150 Watt Power Inverter

1. Using with the Car Engine Off.

You can use the inverter with the engine off, but it will drain the car battery. Estimated usage time formula: Time = Battery AH × 12V / Power (W) × 1.1. A typical car battery (65-70 AH) will last for a limited time, with 1.1 accounting for the inverter’s 90% efficiency.

2. Safety Tips

Ensure proper ventilation and heat dissipation for the inverter.
Keep it away from water and avoid placing heavy objects on it.
Never insert foreign objects into the inverter.
Always turn on the inverter and confirm it’s working before connecting any electrical appliances.
