550W Explosion Proof Portable Exhaust Fan

0 reviews • Write a review

from

$797.69

Ex Tax: $797.69

Stock: In Stock
Model: RDDLZ-EPPEF-550W
Weight: 1.00
SKU: RDDLZ-EPPEF-550W

Available Options

Short Description

Voltage

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

550W explosion proof portable exhaust fans effectively extract and disperse hazardous substances, maintaining a safe and controlled atmosphere in potentially explosive areas. Their portability allows for flexible use in various locations, making them ideal for industrial settings, chemical plants, refineries, and other high-risk environments requiring reliable ventilation systems to minimize the potential for explosions and protect personnel and equipment.

Specification

Model: RDDLZ-BSFT-350
Axis Power: 550W
Motor Power: 550W
Voltage (Optional): 220VAC, 380VAC, 110VAC
Ventilation Duct: 5m (Default)/ Contact Us for Other Sizes
Fan Diameter: 350mm (14 inch)
Impeller Diameter: 340mm (13.5 inch)
Air Volume: 4840~5840m3/h
Static Pressure: 550~500Pa
Rotating Speed: 2800r/min
Frequency: 50/60Hz
Explosion Proof Grade: ExdⅡBT4
Weight: 31kg

Detail

Tips: What is an explosion proof portable exhaust fan used for?

An explosion proof portable exhaust fan is specifically designed and built to operate safely in hazardous environments where there is a risk of explosive gases, vapors, or combustible dust. These fans are crucial for maintaining a safe working environment by effectively ventilating and extracting hazardous substances.

The primary purpose of an explosion proof portable exhaust fan is to prevent the accumulation of flammable or explosive materials, such as gases or dust particles, by constantly circulating the air. By doing so, it reduces the concentration of potentially dangerous substances, minimizes the risk of ignition, and prevents the formation of explosive atmospheres.

These fans are commonly used in various industries, including chemical plants, refineries, pharmaceutical facilities, paint booths, grain elevators, and other environments where volatile substances are present. They feature specialized construction, such as spark-resistant materials, sealed motors, and explosion proof enclosures, to prevent any electrical or mechanical component from causing a spark that could ignite the surrounding hazardous atmosphere.

Overall, the explosion proof portable exhaust fan plays a vital role in safeguarding workers, equipment, and facilities from the potential dangers posed by flammable and explosive substances.
