5 Hp VFD, 1-Phase 220V To 3-Phase 380V VFD

0 reviews • Write a review

from

$473.54

Ex Tax: $473.54

Stock: In Stock
Model: GK3000-CS0037
Weight: 1.00
SKU: GK3000-CS0037

Available Options

Short Description

Input Voltage (Single Phase)

Output Voltage (Three phase)

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

5 hp VFD for sale online, with 1-phase 220V-240V input to 3-phase 380v output, 50Hz/ 60Hz input frequency, 9 amps rated current, 400V/ 415V output are available for selection.

Specification:

Basics	Model	GK3000-CS0037
	Capacity	5 hp (3.7 kW)
	Shipping weight	5 kg
	Dimension	272172182 mm
	Installation size	256*155 mm
I/O Feature	Rated current	9 A
	Input voltage	1 phase 220~240V AC
	Input frequency	50Hz/ 60Hz
	Output voltage (Optional)	3 phase AC 380V/ 400V/ 415V/ 440V/ 460V (Note: 440V, 460V output voltage only for the 1-phase 240V input VFD)
	Output frequency	0Hz~1000Hz
	Over load capacity	150% of rated current for 1 minute, 180% of rated current for 3 seconds
Control Feature	Control mode	V/F control; Sensorless vector control;
	Communication	RS485
	Speed regulation	1:100
	Start torque	150% of rating torque at 1 Hz
	Speed control accuracy	≤±0.5% of rating synchronous speed
	Frequency precision	Digital setting: max frequency x± 0.01%; Analog setting: max frequency x± 0.2%
	Frequency resolution	Analog setting: 0.1% of max frequency; Digital setting: 0.01Hz
	Torque boost	Automatic torque boost, manual torque boost 0.1%~30.0%
	Interior PID controller	Be convenient to make closed-loop system
	Automatic energy save running	Optimize V/F curve automatically based on the load to realize power save running
	Automatic voltage regulation (AVR)	Can keep constant output voltage when power source voltage varies.
	Automatic current limiting	Limit running current automatically to avoid frequent over-current which will cause trip
Environment	Enclosure rating	IP 20
	Temperature	–10℃~ +40℃; VFD will be derated if ambient temperature exceed 40℃; each rise 1℃, the derate will be 5%
	Humidity	5%-95%, without condensation
	Altitude	≤1000m; VFD will be derated if above 1000m
	Impingement and oscillation	Normal running:<5.9m/s2 (0.6g); Transportation:<15m/s2 (1.5g)
	Store environment	–20℃~ +60℃; no dust, no corrosive gas, no direct sunlight

Note: RDDLZ VFD Cannot be used as a power source, it Can only be directly connected to an induction motor to control the motor speed.

Tips: 5 hp 1-phase 220v to 3-phase 380v VFD benefits

5 hp single phase 220v to three phase 380v variable frequency drive can reduce the impact on the grid, it will not cause the problem of excessive peak-to-valley difference.
VFD can accelerate the function controllable, so as to smoothly accelerate according to the needs of the user.
The motor's and equipment stopping mode can be controlled by 1-phase to 3-phase VFD, so that the whole equipment and system is safer and the life span will be increased accordingly.
Controlling the starting current of the motor, fully reducing the starting current and making the maintenance cost of the motor lower.
Can reduce the wear and tear of mechanical transmission parts, thus reducing the purchase cost, and at the same time can improve the stability of the system.
Reduces the motor starting current and provides more reliable variable voltage and frequency.
Single phase 220v to three phase 380v VFD effectively reduce the reactive power loss and increase the active power of the grid.
This 5 hp (3.7kW) VFD can optimize the process and can change quickly according to the process, also can realize the speed change by remote control PLC or other controllers.
