3 Hp VFD, 1-Phase 220V To 3-Phase 380V VFD

0 reviews • Write a review

from

$446.92

Ex Tax: $446.92

Stock: In Stock
Model: GK3000-CS0022
Weight: 1.00
SKU: GK3000-CS0022

Available Options

Short Description

Input Voltage (Single Phase)

Output Voltage (Three phase)

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Affordable price 3 hp (2.2 kW) VFD, features 220v/ 230v /240v single phase input, 380v three phase output. This frequency drive inverter built-in RS485 communication interface, easy to wire and operate.

Specification:

Basics	Model	GK3000-CS0022
	Capacity	3 hp (2.2 kW)
	Shipping weight	5 kg
	Dimension	272172182 mm
	Installation size	256*155 mm
I/O Feature	Rated current	5.1 A
	Input voltage	1 phase 220~240V AC
	Input frequency	50Hz/ 60Hz
	Output voltage (Optional)	3 phase AC 380V/ 400V/ 415V/ 440V/ 460V (Note: 440V, 460V output voltage only for the 1-phase 240V input VFD)
	Output frequency	0Hz~1000Hz
	Over load capacity	150% of rated current for 1 minute, 180% of rated current for 3 seconds
Control Feature	Control mode	V/F control; Sensorless vector control;
	Communication	RS485
	Speed regulation	1:100
	Start torque	150% of rating torque at 1 Hz
	Speed control accuracy	≤±0.5% of rating synchronous speed
	Frequency precision	Digital setting: max frequency x± 0.01%; Analog setting: max frequency x± 0.2%
	Frequency resolution	Analog setting: 0.1% of max frequency; Digital setting: 0.01Hz
	Torque boost	Automatic torque boost, manual torque boost 0.1%~30.0%
	Interior PID controller	Be convenient to make closed-loop system
	Automatic energy save running	Optimize V/F curve automatically based on the load to realize power save running
	Automatic voltage regulation (AVR)	Can keep constant output voltage when power source voltage varies.
	Automatic current limiting	Limit running current automatically to avoid frequent over-current which will cause trip
Environment	Enclosure rating	IP 20
	Temperature	–10℃~ +40℃; VFD will be derated if ambient temperature exceed 40℃; each rise 1℃, the derate will be 5%
	Humidity	5%-95%, without condensation
	Altitude	≤1000m; VFD will be derated if above 1000m
	Impingement and oscillation	Normal running:<5.9m/s2 (0.6g); Transportation:<15m/s2 (1.5g)
	Store environment	–20℃~ +60℃; no dust, no corrosive gas, no direct sunlight

Note: RDDLZ VFD Cannot be used as a power source, it Can only be directly connected to an induction motor to control the motor speed.

5 tips for using 1-phase 220V to 3-phase 380V VFD

The power at the input of the variable frequency drive must be sufficient, otherwise the operation will jump under voltage fault can not be normal operation.
Single phase 220v to three phase 380v VFD belongs to the boost circuit step-up, for the load side of the maximum for the light-load site below 30hp (22kW), in terms of selection, the light-load motor use a large level of VFD, heavy-load site use a large two-level VFD.
1-phase to 3-phase VFD can only be used for motor class inductive load, can not be used as other load power supply.
The VFD is not suitable for the need to quickly start and stop the site, and the occasion of the bit energy load.
Part of the equipment motor can be used by changing the motor connection three-phase 220V electricity (such as motor star connection state is three-phase 380V motor, can be changed to delta connection can use three-phase 220V, the specific can consult the motor manufacturer), at this time can buy RDDLZ single-phase 220V to three-phase 220V VFD to solve the problem of phase change.
