Affordable 45mm linear guide block can move smoothly on the linear track. The length of the linear rail can be customized to match the linear slider. 300mm~1500mm CNC linear rail length for selection. Linear guideways can achieve high speed, high precision and smooth linear motion, and are suitable for most automation requirements.

Guide Block Features

55mm guide block with high speed, low friction and noise, high precision, long working period, high reliability, smooth movement, high transfer efficiency, no clearance and preload is available online.

Applications

RDDLZ linear guides with guide blocks are widely used in CNC precision machining, heavy-duty cutting machines, punching machines, marble cutting machines, automation equipment, grinding machines, high-speed transfer equipment and injection molding machines.

Specifications

• Model: RDDLZ-HGWCC55
• Block Mounting: Top to Bottom
• Sliding track: Linear guideways

Construction of CNC Linear Rail and Guide Block

1500mm Linear Rails with 55mm Guide Block Dimensions

Datasheet (Unit: mm)

Tips: What is linear rail?

A linear rail allows a type of linear motion that utilizes rolling elements such as balls or rollers. By using recirculating rolling elements between the rail and the block, a linear guideway can achieve high precision linear motion. Compared to a traditional slide, the coefficient of friction for a linear guideway is only 1/50. Because of the restraint effect between the rails and the blocks, linear guideways can take up loads in both the up/down and the left/right directions. With these features, linear guideways can greatly enhance moving accuracy, especially, when accompanied by precise ball screws.
