1 Hp (0.75kW) 220V Single Phase AC Induction Motor

0 reviews • Write a review

from

$315.98

Ex Tax: $315.98

Stock: In Stock
Model: RDDLZ-SPM-750
Weight: 1.00
SKU: RDDLZ-SPM-750

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Hot selling 1 hp 220V single phase motor with a start capacitor and run capacitor, 110V/230V/240V is available. 1500rpm/3000rpm for selection. 0.75kW AC 1 phase motor works at 50/60 Hz and provides zero starting torque at rest, perfect for drills, air conditioners, compressors, pumps, cranes, garage door opening and closing systems.

Specifications

Model	RDDLZ-YL801-2	RDDLZ-YL711-4
Rated Output	0.75kW (1hp)
Efficiency	72%	71%
Power Factor	0.92 COSφ
Rated Speed	2800rpm	1400rpm
Rated Current	4.93A	4.99A
Pole	2 Pole	4 Pole
Voltage	220V AC 50Hz (Default), other customizations can be customized.
Tmax/Tn	1.8 times
Ts/Tn	1.8 times
ls/ln	29 times	29 times

Dimension (Unit: mm)

Frame Size	Mounting Dimension									Overall Dimension
Frame Size	A	B	C	D	E	F	G	H	K	AB	AC	AD	AE	HD	L
71	112	90	45	14	30	5	11	71	7	145	145	140	105	180	255
80	125	100	50	19	40	6	15.5	80	10	160	165	150	120	200	295

Details

Tips: What is the role of the capacitor in the single phase motor circuit?

Since the single phase motor has only one-phase alternating current, although the magnetic field is also rotating, there is no starting torque, which causes the motor to fail to rotate after being energized. It needs an external force to start the rotor. Therefore, people use the characteristics of the capacitor to change the original alternating current by a phase difference and connect it to a starting coil in the motor to generate a starting torque so that the motor can rotate. It can be said that this capacitor plays the role of starting, also called the starting capacitor.
