- Stock: In Stock
- Model: GS280
- Weight: 1.00
- SKU: GS280
Factory price 350 hp soft starter for sale online, 280 kW three phase 380V, 400V, 440V, 460V or 480V AC motor soft starter can be selected, make motor in soft start & soft stop, buy from manufacturer directly.
| Model | GS3-280 (380v, 400v, 440v), GS4-280 (460v, 480v) | ||
| Capacity | 350 hp (280 kw) | ||
| Current | 560 amps | ||
| Weight | 21 kgs | ||
| Dimension | 525*257*194 mm | ||
| Input | Voltage | Three-phase 240v, 400v, 480v, 690v AC | |
| Frequency | 50Hz/ 60Hz | ||
| Adaptive Motor | Squirrel-cage three-phase asynchronous motor | ||
| Starting Times | It is recommended not to exceed 20 times per hour. | ||
| 485 Communication | DB9 interface, male plug, ① is RS485+, ⑥ is RS485- | ||
| Control Mode |
| ||
| Start Mode |
| ||
| Stop Mode |
| ||
| Protective Function |
| ||
| Ambient | Place to be used | Indoor location with good ventilation free from corrosive gas and conductive dust. | |
| Altitude | Below 1000M. It has to increase the soft starter rate power when the altitude is more than 1000M. | ||
| Temperature | -30 +55 oC | ||
| Humidity | 90%RH without dew condensation. | ||
| Vibration | <0.5G | ||
| Structure | Enclosure | IP 20 | |
| Cooling | Natural wind cooling. | ||
Details
Tips: What is a soft starter?
A soft starter is an electronic motor control device designed to gradually accelerate an AC induction motor to its full speed by controlling the voltage applied to it during the startup phase. Instead of applying full line voltage instantly—which causes a high inrush current and sudden torque—a soft starter uses a series of thyristors (SCRs) to ramp up the voltage smoothly over a preset time. This process significantly reduces the inrush current (typically to 2-4 times the full-load current) and minimizes mechanical stress on the motor, shaft, and connected machinery, such as belts, gears, or pumps. Once the motor reaches full speed, an internal bypass contactor energizes, allowing current to flow directly to the motor, thus improving the efficiency and thermal performance of the soft starter during steady-state operation. Its primary benefits include protecting equipment from wear and tear, preventing water hammer in pumping systems, and mitigating voltage dips in the electrical supply.
