3" Stainless Steel Flanged Gate Valve

0 reviews • Write a review

from

$938.99

Ex Tax: $938.99

Stock: In Stock
Model: RDDLZ-FGV-DN80
Weight: 1.00
SKU: RDDLZ-FGV-DN80

Available Options

Short Description

Working Pressure

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Note: This gate valve cannot be used for drinking water.

3 inch stainless steel flanged gate valve features an OS&Y (Outside Screw and Yoke) design, allowing easy identification of its position and enhancing its reliability. It is indispensable in maintaining control and reliability in high pressure water systems.

Specification

Model: RDDLZ-ANSI-DN80
Connection Type: Flanged Type
Flanged Port Size: 3 inch (DN80)
Working Pressure (Optional): CLASS150/300
Working Temperature: -425℃
Valve Body Material: Stainless Steel
Applicable Media: Water, Chemical, Petroleum, Gas, etc.

Detail & Dimension

Number	Part Name	Material
1	Body	CF8
2	Disc	CF8
3	Steam	304 Stainless Steel
4	Gasket	PTFE
5	Bonnet	CF8
6	Bolt	304 Stainless Steel
7	Nut	304 Stainless Steel
8	Packing	PTFE
9	Clevis Pin with Head	304 Stainless Steel
10	Split Pin	304 Stainless Steel
11	Gland	CF8
12	Eye Bolts	304 Stainless Steel
13	Flat Pad	304 Stainless Steel
14	Nut	304 Stainless Steel
15	Steam Nut	Bronze
16	Bonnet Nut	304 Stainless Steel
17	Handwheel	WCB
18	Round Nut	304 Stainless Steel

Working Pressure	Nominal	Diameter	L	d	D2	D1	D	b	f	n-φd1	H	W
CLASS150	DN80	3 inch	203	80	127	152.4	190	17.5	2	4-19	433	250
CLASS300	DN80	3 inch	282	80	127	168.3	210	27	2	8-22	443	300

Tips: What are the advantages of flanged gate valves?

Flanged gate valves offer several advantages in fluid control systems. First, their robust construction ensures durability and reliability in high-pressure and high-temperature applications. The flanged design allows for easy installation and maintenance, facilitating quick removal and replacement without disrupting the entire pipeline. Additionally, flanged connections provide a secure and leak-resistant seal, minimizing the risk of fluid loss. The gate valve's straightforward operation, with a simple open or close mechanism, allows for efficient flow regulation, making it suitable for on/off applications. These valves also exhibit low pressure drops when fully open, optimizing energy efficiency. Overall, the advantages of flanged gate valves include durability, ease of installation and maintenance, secure sealing, efficient flow control, and suitability for demanding industrial conditions.
