3/4" Stainless Steel Wafer Check Valve

0 reviews • Write a review

from

$57.66

Ex Tax: $57.66

Stock: In Stock
Model: RDDLZ-SSWCV-34
Weight: 1.00
SKU: RDDLZ-SSWCV-34

Available Options

Short Description

Material

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

3/4 inch stainless steel check valve is a wafer type non return valve, used to allow fluid or gas flow in one direction while preventing backflow in the opposite direction. Lightweight wafer disc check valve with DN 20 and PN 4MPa can be installed in tight spaces.

Specifications

Model: RDDLZ-H71W
Check Valve Type: Wafer
Nominal Diameter: 3/4 inch (20mm)
Nominal Pressure: 4 MPa
Product Material: 304/316 Stainless Steel
Connection Form: Clip
Temperature Range: -20°C~180°C
Weight: 0.22kg
Applicable Medium: Water, Oil, Gas, Nitric Acid, Acetic Acid

Details

Main Part Materials
NO.	Part Name	Materials	QTY
1	BODY	CF8/CF8M	1
2	DISC	CF8/CF8M	1
3	SPRING	S201/S304	1
4	CAP	CF8/CF8M	1
Dimension (Unit: mm)
Φd	D	D1	L±1.5
17	50	54	29

Applications

Wafer check valve is a type of check valve that is used to regulate and control the flow of fluids through pipelines while preventing backflow. High quality wafer check valve is typically used in applications where space is limited, such as in HVAC systems, water treatment plants, and industrial processes.

Tips: What are the advantages of a wafer check valve?

Wafer check valves offer several advantages over other types of check valves and are a popular choice for many applications. Some of the key advantages of wafer check valves include:

Compact Design: Wafer check valves are lightweight and have a slim profile, which makes them ideal for use in applications where space is at a premium.
Easy to Install: The wafer design of these valves allows them to be easily installed between flanges, which saves time and money during installation.
Cost-Effective: Wafer check valves are often less expensive than other types of check valves, making them an affordable solution for many applications.
Low Pressure Drop: Wafer check valves offer low pressure drop across the valve, which means that the system operates more efficiently.
Versatile: Wafer check valves are suitable for a wide range of applications, including HVAC systems, water treatment plants, and industrial processes.
Low Maintenance: Wafer check valves are generally easy to maintain, and require minimal maintenance compared to other types of valves.
Effective Backflow Prevention: Wafer check valves provide effective backflow prevention, which helps to protect equipment from damage due to reverse flow or water hammer.
