2 Inch Pilot Operated Pressure Relief Valve, DN50

0 reviews • Write a review

from

$355.38

Ex Tax: $355.38

Stock: In Stock
Model: RDDLZ-POPRV-DN50
Weight: 1.00
SKU: RDDLZ-POPRV-DN50

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Note: This pressure relief valve cannot be used for drinking water.

High-performance operated pressure relief valve with DN50 nominal diameter, nominal pressure is 16 MPa. The pressure release valve has voltage reduction and regulation, large adjustment range.

Features

Pilot-operated valves for limiting a system pressure
Operation using proportional solenoid
Maximum pressure limitation
Valve and control electronics from a single source
Little manufacturing tolerance of the command value
Pressure characteristic curve

Details

Specification

Model: RDDLZ-200X-DN50
Size: 2 inch
Nominal diameter: DN50
Structural form: Diaphragm type
Pressure rating: PN16
Shell test pressure: 2.4 MPa
Sealing test pressure: 1.76 MPa
Ambient temperature: ≤80℃
Connection method: Flange
Medium: Water
Valve body material: Ductile iron QT450

Dimension

Dimension	L	D2	D1	x-n	T	F	D
DN50	215mm	165mm	125mm	4-φ19	20mm	3mm	99mm

Installation

Notes

It is recommended to install an exhaust valve on the top of the riser to make the pressure reducing valve work more smoothly.
Before installing the pressure relief valve, check the valve for unusual items and be sure to flush the pipeline.
Installation method: Horizontal or vertical installation, single valve set.

Pressure Relief Valve Application

Tips: What is a pilot operated pressure relief valve?

The pilot-operated pressure relief valve adjusts the flow of the medium by controlling the opening of the opening and closing parts in the valve body and reduces the pressure of the medium. Within a certain range, when the inlet pressure is constantly changing, keep the outlet pressure within the set range to protect subsequent living and production appliances.
