2-1/2" 3 Way Diaphragm Valve

0 reviews • Write a review

from

$466.09

Ex Tax: $466.09

Stock: In Stock
Model: RDDLZ-3WDV-DN65
Weight: 1.00
SKU: RDDLZ-3WDV-DN65

Available Options

Diaphragm Material

Textarea

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

3 way stainless steel diaphragm valves provide precise control over liquids and gases, making them suitable for processes that require accurate modulation or diversion, commonly used in industrial applications.

Specification

Model: RDDLZ-3WDV-DN65
Size: 2-1/2 inch (DN65)
Driving Mode: Manual, with Closing Limit Device
Maximum Working Pressure: 10bar (Ethylene Propylene Rubber or Fluorinated Rubber Diaphragm), 6bar (Polytetrafluoroethylene Diaphragm)
Maximum Operating Temperature: 150℃ (Depending on Usage Conditions)
Diaphragm Material (Optional): Ethylene Propylene Rubber, Fluorinated Rubber, Polytetrafluoroethylene
Valve Body Material: 316L Stainless Steel
Interface Mode: Quick Installation (Tri Clamp Connection)

Dimension (Unit: mm)

Size	D	L	L1	T
2-1/2 inch (DN65)	63.5	190.5	165.1	1.65

Application

Tips: What maintenance is required for a 3 way diaphragm valve?

Maintenance for a 3 way diaphragm valve involves routine inspection and occasional replacement of the diaphragm. Regularly check for signs of wear, tearing, or damage to the diaphragm, which may affect the valve's performance. Cleaning and flushing the valve to remove any accumulated debris or contaminants are essential. Depending on the application, it is recommended to follow the manufacturer's guidelines for diaphragm replacement intervals. Proper lubrication of moving parts, inspection of the actuator, and ensuring that the valve is operating within its specified parameters contribute to longevity and reliability. Maintenance practices help prevent leaks, maintain optimal flow control, and extend the overall lifespan of the three way diaphragm valve in various industrial applications.
