100A High Voltage DC Contactor, 12V/24V Coil

0 reviews • Write a review

from

$118.92

Ex Tax: $118.92

Stock: In Stock
Model: RDDLZ-DCCON-HV100
Weight: 1.00
SKU: RDDLZ-DCCON-HV100

Available Options

Short Description

Coil Rated Voltage

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Features

DC 12-900V rated load voltage of contact circuit.
normally open type (SPST-NO), 12 volt, 24 volt coil for selection.
Main contact voltage drop at 100A, not above 100mV.
The connection of contact and coil need to be nonpolarity.
Efficient coil, retentive power is only 2-2.3W, counter electromotive force is 0V.
The joint way of the coil is very convenient.
The coil has no counter force of electromagnetism.
Compare to the similar products, this product is smallest and lightest.

Specifications

Basics	Model	RDDLZ-ADH100
	Dimension	55 x 42 x 62 mm
	Weight	230 g
Main Contact Parameters	Contact Form	1 NO
	Leading-Out	M5 internal thread/18 mm
	Rated Load Current	100 A
	Rated Load Voltage	12 – 900V DC
	Maximum Switching Current	1000A 320V DC (≥1 times)
	Maximum Switching Power	320 kW
	Rated Electric Life	10,000 times
Coil Parameters	Standard Type Voltage	12V DC	24V DC
	Work Voltage	9~16V	18~32 V
	Max Voltage	16 V	32 V
	Coil Resistance	26 Ω	96 Ω
	Average Holding Current	0.46 A	0.25 A
	Steady State Power	5.5 W	6 W
	Actuation Time	≤25 ms
	Release Time	≤10 ms
	Bounce Time	≤5 ms
Mechanical Specification	Stability	196 m/s²(20G)
	Strength	490 m/s²(50G)
	Vibration	80 ~2000Hz 98m/s²(20G)
	IP Grade	IP67
Environment	Operating Temperature	-40℃~85℃
	Operating Humidity	5~95% RH

Installation Diagram (Unit: mm)
High Voltage DC Contactor Coil Schematic

Details

Tips: Contacts of DC contactor
In the selection of a DC contactor, control method of the application circuit shall be considered firstly, as well as the role of the contactor in the circuit, because the main contact of DC contactor includes two types of single and double. Single contact contactor is mainly used in electric system, or other independent variable current systems, its functions are: 1 Ready to run; 2 Quickly cut off main circuit in case of accident state. Therefore, the rated current, rated voltage and arc breaking capacity of the contactor must meet the system requirements. Double contacts contactor is mainly used for non independent power supply system or bilateral system, pay attention to the rated current, rated voltage and arc breaking capacity. Finally, the coil suction voltage shall comply with the requirements of operating system. When the suction coil is large, add RC absorption loop to prevent the self-inducing potential to break through itself or relevant equipment.
