1/2" Stainless Steel Globe Valve
from
$108.95
Ex Tax: $108.95
- Stock: In Stock
- Model: RDDLZ-GV-12SSGV
- Weight: 1.00
- SKU: RDDLZ-GV-12SSGV
Available Options
Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.
Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.
Simple and compact appearance of stainless valve. Globe control valve can be used in machinery and petrochemical industry. Working temperature of this type globe valve between -20 ℃ and 260 ℃.
Features:
- Simple and compact appearance.
- NPT threaded connection for easy installation of pressure gauge and pipe.
- 304 stainless steel has the characteristics of corrosion resistance and high temperature resistance.
Specification:
- Model: RDDLZ-HNV-N08MF
- Port Size: 1/2 inch
- Structure: inner and outer thread
- Pressure: 0-6000 psi
- Temperature: -20 ℃ ~ + 260 ℃
- Medium: oil, water, steam
Dimension (Unit: mm)
Model | T | L | S | A | B |
HNV-N08MF | NPT 1/2" | 75 | 28 | 103 | 50 |
Tips: How to Choose Globe Valve?
- Pneumatic high pressure globe valves should be selected for pipelines or devices with high temperature and high pressure media.
- The direct flow globe valve should be selected on the pipeline where the convection resistance is not strict.
- Small pneumatic globe valve can choose needle valve, instrument valve, sampling valve, pressure gauge valve, etc.
- There is flow regulation or pressure regulation, but the adjustment accuracy is not high, and the pipe diameter is relatively small, such as nominal passage ≤50 mm pipeline, the best choice of pneumatic globe valve, electric globe valve.
