0~30 Psi Pressure Gauge, 0 To 2 Bar

0 reviews • Write a review

from

$47.67

Ex Tax: $47.67

Stock: In Stock
Model: RDDLZ-PG-30
Weight: 1.00
SKU: RDDLZ-PG-30

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Note: This pressure gauge cannot be used for drinking water.

Buy a 0 to 30 psi pressure gauge online. It is a diaphragm pressure gauge with brass and stainless steel wetted parts for measuring water, oil, liquid and gas pressure, comes with a dual scale, 40mm dial diameter, stainless steel, 1/8" BSPT thread specification for connection, pressure measurer is mainly used in metallurgy, electric power, petroleum, chemical industry, etc.

Specifications

Model: RDDLZ-TS-Y408-30psi
Dial Diameter: φ40mm
Installation Method: Radial
Range: 0~30 psi, 0~2 bar
Installation Diameter: 1/8
Thread Specification: BSPT
Size: 6x4x2.5cm
Material: Stainless Steel
Package Size: 8.5x6.5x4.5cm
Product Weight: 44g
Package Weight: 60g

Features

0 to 30 psi pressure gauge can be used as a water pressure gauge, air pressure gauge, hydraulic pressure gauge and oil pressure gauge.
RDDLZ pressure gauge equipped with dual scale (0~15 psi/0~1 bar), and a lower-mount male connection with a 1/8" BSPT thread.
The circular dial is enclosed in a stainless steel case for corrosion resistance, portable 0~1 bar pressure gauge offers clear readings and is weather-resistant.
Display accuracy of 2.5% over the entire range of the gauge.
Brass and stainless steel wetted parts for measuring non-corrosive liquid and gas pressure. Such as water, oil, fuel, coolant, air, co2, nitrogen, and argon pressure test.

Dimension (Unit: mm)

Details

Applications

Pressure gauge is the most commonly used measuring instrument for displaying and controlling pressure, widely used in the chemical industry, petroleum, metallurgy, mining, and electric power production, especially in vehicle maintenance shops, heat pipe networks, water and gas supply systems, etc.

Tips: How does a pressure gauge work?

The pressure gauge transmits the pressure deformation to the pointer through the elastic deformation of the sensitive components (Bourdon tube, diaphragm box, bellows) in the watch, and then the conversion mechanism of the watch movement, causing the pointer to rotate to display the pressure. This is the working principle of a pressure gauge.
