Serial To Fiber Converter

0 reviews • Write a review

from

$182.70

Ex Tax: $182.70

Stock: In Stock
Model: RDDLZ-UT-2788SM
Weight: 1.00
SKU: RDDLZ-UT-2788SM

Available Options

Short Description

Fiber Port

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Cost-effective serial to fiber optic converter with AC/ DC100-240V, 1W input voltage, RS 232 has standard 3 bits ±15kV ESD protection, as high as 115.2kbps transmission rate, RS485/ 422 has auto negotiation, no need switch setting, ±15kV ESD protection.

Specification

Model	RDDLZ-UT-2788SM
Port	RS232/ RS485/ RS422 ports
Asynchronous transmission	Point to point, 460kbps
Transmission distance	4000m (multimode mode), 20000m (single mode)
Operating temperature	-40-85℃
Operating wavelength	1310 nm
Interface	RS232/ RS485/ RS422: Terminal block; fiber port: optional SC/ FC/ ST
Input voltage	AC/ DC100-240V, 1W
RS-232	Standard RS-232 3 bits ±15kV ESD protection, as high as 115.2kbps transmission rate
RS-485/ 422	Auto negotiation, no need switch setting, ±15kV ESD protection
Certificate	CE
Warranty	12 months

Dimension (inch/ mm)

Tips: Features of Fiber Converter.

1. Two forms of power interface are provided at the same time, terminal method and socket method, whichever can be connected in actual use.
2. Provide power and signal direction (← and →) three indicator lights to facilitate users to check the communication status.
3. The shell is made of metal and iron, which is sturdy and durable. It can be installed on a panel or on an industrial rail.
4. Optical fiber interface adopts dual FC (FIBER-TX, FIBER-RX) interface.
5. The physical interface of the serial port is in the form of 12-hole binding posts.
6. The serial port provides RS232, RS422 and RS485 three interfaces at the same time, which has a wider application range.
