NDIR CO2 Sensor Module, 0 To 10000 Ppm

0 reviews • Write a review

from

$126.03

Ex Tax: $126.03

Stock: In Stock
Model: RDDLZ-ICDS-Z14B
Weight: 1.00
SKU: RDDLZ-ICDS-Z14B

Available Options

Short Description

Measuring Range

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Cheap price NDIR CO2 gas sensor with average current less than 60mA, preheat time 10s, the working humidity is 0~95% RH. Infrared carbon dioxide sensors are widely used in various occasions where flammable and explosive gases exist.

Features

High sensitivity, high resolution
Low power consumption
Output modes: UART, analog voltage signal, PWM wave
Quick response
Temperature compensation, excellent linear output
Good stability, long lifespan
Anti-water vapor interference
Anti-poisoning

Specification

Model: RDDLZ-ICDS-Z14B
Detection gas: CO2
Average current: <60mA (@5V power supply)
Peak current: 150mA (@5V power supply)
Interface level: 3.3V
Measuring range: 0~10000ppm (max 50000ppm can be extended)
Output signal: UART (TTL 3.3V)/ PWM
Preheat time: 10s
Response time: T90 < 90s
Working temperature: -10℃ ~ 50℃
Working humidity: 0~95% RH (no condensation)
Storage temperature: -20℃ ~ 60℃
Dimension (L*W*H): 57.5*34.7*17mm

Measuring range and accuracy

Target gas	Measuring range	Solution	Accuracy
Carbon Dioxide	0~2000 ppm	1ppm	±（50ppm+5% reading value）
	0~5000 ppm
	0-10000 ppm

Dimension (mm)

Tips: Working Principle of NDIR CO2 Gas Sensor?

This type of CO2 sensor module is an intelligent general-purpose, small sensor that detects CO2 in the air using the principle of non-dispersive infrared (NDIR). Good selectivity, no oxygen dependence, long life. Built-in temperature compensation; digital output and analog voltage output at the same time, easy to use. Carbon dioxide sensor is a high-performance product that closely combines mature infrared absorption gas detection technology with precise optical path design and precise circuit design. The sensor can be used to monitor production processes in smart homes, agricultural greenhouses and animal husbandry.
