G3/4" Pneumatic Shuttle Valve

0 reviews • Write a review

from

$77.89

Ex Tax: $77.89

Stock: In Stock
Model: RDDLZ-PSV-ST06
Weight: 1.00
SKU: RDDLZ-PSV-ST06

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Note: This shuttle valve cannot be used for drinking water.

Pneumatic shuttle valves are commonly used in applications where it's necessary to switch between two pneumatic circuits or devices using a single control signal. They can be found in various industrial applications, such as automated manufacturing processes, pneumatic control systems, and robotics.

Specification

Model: RDDLZ-ST-06
Working Medium: Air
Effective Sectional Area: 110mm²
Joint Pipe Port: G3/4 inch
Working Pressure Range: 0~0.8MPa
Operating Temperature Range: 0~60℃

Dimension (Unit: mm)

Model	A	B	C	D	E	F	G
RDDLZ-ST-06	110	72	40	7	70	58	G3/4"

Tips: How to troubleshoot common issues with pneumatic shuttle valves?

To troubleshoot common issues with pneumatic shuttle valves, start by checking for air leaks, as they can compromise the valve's function. Ensure proper installation and connection of tubing, and inspect for any damage or blockages. Verify that the shuttle valve is correctly aligned and not jammed. If the valve fails to switch between ports, assess the actuation mechanism for wear or misalignment. Confirm that air pressure is within the specified range and that the supply is clean and dry. Additionally, inspect seals and O-rings for damage and replace if necessary. If problems persist, consult the manufacturer's documentation for specific troubleshooting steps or consider seeking professional assistance. Regular maintenance and adherence to manufacturer guidelines are crucial for optimal pneumatic shuttle valve performance.
